The Atlas Sound DSP2210/DSP2212 digital processor "Privacy" system is a self contained, compact multi-zone digital DSP-GUI controlled processor and digital amplifier capable of simultaneous distribution of masking, paging, and background music signals for use in Industrial, Institutional, Commercial and Government facilities.The Atlas Sound DSP2212 is capable of automatic mixing, set up and administration of all inputs/outputs per zone (channel). This is accomplished via an intuitive ‘simple to use' Graphic User Interface (GUI) managed via a local laptop or desktop computer that is running Microsoft Windows It provides up to 2 channels of independent on-board digital Class-D amplifiers rated at 25W RMS at 70V. It has a pink noise generator which is random and non-repeating up to (215) hours with EQ adjustments programmable on a per zone basis.
The DSP's provide dynamic control and management based on IEEE802.1 AVB standards (Audio-Video Bridging) with independent 1⁄3 Octave (28) band EQ *(Filter type is Butterworth at 19dB and Linkwitz-Riley at 24dB) and Parametric EQ 8-band for calibration of all PA and masking signals on a per zone basis. Paging (PA) levels are adjustable in 0.5dB increments per zone on Line Level (Music) and Microphone paging inputs. The system has the ability to expand up to (32) systems (64 zones) with primary and secondary assignment in a zone paging dialing plan. It also provides the ability to set up "All Zone" and "Group zone" pages through the GUI.- Features
Features
- Two Channels of Random Pink Noise Generator Non-Repeating Up to 215 Hours
- Two Audio Outputs of 25 Watts RMS Digital Class-D Amplification at 85% Efficiency
- IEEE802.1 AVB (Audio Video Bridging) Technology for Time Aligned Networking of Multiple Units
- Multiple Audio Source Inputs for Background Music and Paging
- On-Board MAC Address for IP Addressability Compatible with DHCP Server
- Zone Expansion From 2 to 64 Via Standard Ethernet LAN
- All-Call Page, Group Zone Page and Single Zone Page Defined in GUI
- Visual Status Front LCD Display for All Major Input and Output Control Functions
- UL / CUL / FCC and CB (International) Listed
- Specification
System Performance / DSP Processors Dynamic Range >102dB A-Weighted Frequency Response 80Hz – 20kHz ± 3dB at Rated Output Distortion THD+N .001% Typical at +4dBu, 1kHz,0dB Gain Input Sensitivity 2Vrms Max 20KΩ Interchannel Crosstalk > 80dB Typical Crosstalk Input to Output > 80dB Channel Separation > 100dB at 1kHz (In Thru Out) Common Mode Rejection Ration (CMRR) > 50dB, 20Hz – 20kHz Typical > 55dB at 1kHz Processor Capacity Fixed Point, Audio Specific Sample Rate Audio Conversion 48kHz D/A Converter Type (Audio) 24-Bit Sigma Delta D/A Performance Dynamic Range (Converter) > 100dB A-Weighted A/D Performance Dynamic Range > 110dB A-Weighted Non-Volatile Memory Memory Storage for All Programs & Set Up Protectedfor (24) Hours In Power Brown Out, Interruption Non-Volatile Memory Computer Shut Down. Data Settings Good for (10) Years W/O Refresh CODEC – DSP Protection All I/O Protected With Buffers From Spikes and Transients or Sneak Currents System Inputs Power AC Mains IEC 3-pin With Ground, 80-240VAC, 50-60HZ Network RJ45 Module Jack (EIA 568B) Microphone 3-pin Dockable Keyed Connector Background Music RCA Connector 10KΩ (Sum ToMono) System Outputs Zone Speakers 2-pin Dockable Keyed Connector (70V @ 25W RMS) Network System Link RJ45 Modular Jack (EIA 568B) [Unit #2 - #32] System Amplifiers Frequency Response 80Hz – 20kHz, ±3dB Total Distortion .001% Typical at +4dB, 1kHz, 0dB Gain Transformer Output 70.7V Efficiency 85% or Better Gain Control Adjustable to 34dB Power Supply UL / CUL Recognized Input Impedance 50kΩ Carrier Frequency 400kHz Peak current 1.2A MTBF (Mean Time Between Failure) 100,000 hours EMC / EMI radiation FCC Part 15 Class B, EN6100, CISPR 22 System Mechanical Data Material (Outer Housing) CRS (Cold Roll Steel) 18 AWG (.047" Nominal) Finish Flat Black Powder Coat With Zinc Undercoat Corrosion Resistant Printed Circuit Boards UL Recognized UL94VO Electronic Components RoHS Operating Temperature 0˚ to +50˚C Storage Temperature -40˚ to +85˚C Humidity 95% Non-Condensing (Max.) Dimensions (H x W x D) 1.75" (44.5 mm) x 19" (482.6 mm) x 10" (254 mm) Weight 12 lbs (5.44 kg) - Reviews
