- Description
Details
The PS602P is a 2-channel portable amplifier that allows its total 600 watts to be shared across both outputs. Independently control the output level, EQ, and low-impedance/high-impedance (Low-Z/Hi-Z) settings for each output. Onboard configurable loudspeaker processing eliminates the need for an additional signal processor in many installations, while outstanding audio performance and reliability are assured with patented technologies inherited from the field-proven PowerMatch® line. This unique set of features and technologies makes PowerShare one of the most versatile high-performance amplifiers available.
Applications:
- Performing arts venues
- Houses of worship
- Conference centers
- Retail stores
- Restaurants and bars
- Hospitality venues
- Features
Features
- PowerShare Technology - Patented PowerShare technology allows the total 600 watts of power to be shared asymmetrically across all outputs, as each output is capable of delivering full power. Instead of selecting amplifier power based on the needs of the largest zone, installers now have the freedom to use total amplifier power in the application. This enables more flexibility during the initial design, or later on-site when making unplanned changes that take advantage of surplus power.
- Load-Independent Outputs - Each channel can be configured for low-impedance (4-8 Ω) or high-impedance (70/100V) applications without bridging, use of jumpers, or software settings.
- DFL™ System - The Dual Feedback Loop system, inherited from the field-proven Bose PowerMatch® amplifier line, improves performance and reliability through continuous monitoring and control of both the current and voltage delivered to each output load. This combination provides improved linearity and lower distortion, while protecting loudspeakers.
- Integrated Loudspeaker Processing with Optional PowerShare Editor Configuration - For applications requiring additional signal processing the PowerShare Editor Software offers real-time selection and control of Bose loudspeaker EQs, 9-band PEQs, mixing, crossover, limiters, delay, and mute/output polarity through a USB connection. For basic setups without a PC, rear-panel settings allow installers to recall Bose loudspeaker equalization and protection per output channel. These features eliminate the need for an external signal processor in many applications.
- Auto-Standby - Designed to save power consumption when not in use. PowerShare amplifiers can be configured to automatically enter standby mode when the audio signal falls below a set threshold, then wake when audio returns.
- Specification
Power Rating Amplifier Power 2 x 300W (THD+N < 0.04%, 1kHz, 4 - 8Ω, 70/100V) Maximum Power Per Channel 600W @ 4 - 8Ω, 70/100V Gain (Low-Z mode) 44dB, RCA (unbalanced) inputs; 32dB, Euroblock (balanced) inputs Gain (70V mode) 47dB, RCA (unbalanced) inputs; 35dB, Euroblock (balanced) inputs Gain (100V mode) 50dB, RCA (unbalanced) inputs; 38dB, Euroblock (balanced) inputs Audio Performance Frequency Response 4 - 8Ω: 20Hz – 20kHz (+/- 0.5dB @ 1W); 70/100V: Same as 4 - 8Ω with 50Hz high-pass filter Channel Separation (Crosstalk) > 85dB @ 1kHz, > 65dB @ 20kHz Signal to Noise Ratio 100dB (at rated power, A-weighted) Audio Inputs Input Channels 2 unbalanced, 2 balanced Connectors Stereo RCA, XLR/TRS Input Impedance 10kΩ (RCA), 20kΩ (XLR/TRS) Maximum Input Level 20dBu (at 12dBu sensitivity setting) Sensitivity -10 / -2dBV, RCA inputs; 4 / 12dBu, Euroblock inputs (low / high sensitivity) Audio Outputs Outputs 2 Connectors NL4 & binding posts Integrated DSP A/D and D/A Converters 24-bit / 48 kHz Processing Functions Matrix mixer, loudspeaker EQ, real-time 9-band PEQ, Vpeak/Vrms limiters, delay, band pass, mute/output polarity inversion Loudspeaker Presets Flat, DS16, DS40, DS100, FS3B, 402, 802, MA12EX, RMU105 and RMU108 Audio Latency < 1 ms (any input to speaker output) Indicators and Controls Power LED Solid green: Power is onBlinking green: Unit is in standby modeSolid amber: Thermal faultSolid red: Supply fault Input Signal LED Green: Signal presentAmber: Input is near clippingRed: Input is clippingSolid red: Indicates a fault Output Limit LED Amber: Amplifier limiting an outputBlinking red: Amplifier mutedSolid red: Indicates a fault Controls, Front Panel Power On/Off, Output Level Control Controls, Rear Panel Amplifier mode DIP switches, loudspeaker EQ dials Electrical Mains Voltage 100 VAC – 240 VAC (±10%, 50/60Hz) AC Power Consumption 120 VAC: 14W (Standby), 700W (Max)230 VAC: 14W (Standby), 700W (Max) Mains Connector Standard IEC (C14) Maximum Inrush Current 14.14 A (230 VAC / 50Hz), 8.04 A (120 VAC / 60Hz) Protections High temperature, output short, extra high frequency (EHF), excessively low or high AC line voltage Dimensions (H x W x D) 1.7" (44 mm) x 19" (483 mm) x 16.3" (414 mm) Weight 12.2 lbs (5.5 kg) - Documents
