JBL Nano Patch+ Compact 2-Channel Stereo Passive Volume Controller (Discontinued)
Part # NPATCH BLK
Model # Nano Patch+

JBL Nano Patch+ Compact 2-Channel Stereo Passive Volume Controller with rotary volume attentuation control for computer audio soundcards, CD players, pre-amps, and mixers.

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

The Nano Patch+ is a versatile passive volume controller in a compact desk-top format. A great way to passively attenuate stereo signals from computer audio soundcards, CD players, pre-amps, and mixers, the Nano Patch+ is designed to allow precise adjustment of monitoring levels from analog audio source material. Featuring balanced combo XLR/TRS input jacks and TRS outputs, as well as 3.5mm Minijack connections, mute switch and a large rotary volume control, the Nano Patch+ is a valuable addition to your studio. The Nano Patch+ employs passive circuit design for a high quality signal path. It simply delivers attenuated signal. Pure, simple transparent.

Audio Connections

The NanoPatch+ accommodates balanced and unbalanced signals with its combo input jacks, and TRS 1/4-inch (6.5mm) outputs.

Input Connections

The main stereo inputs are located on the rear panel and feature XLR balanced/unbalanced combo connectors for Left and Right input signal. These are ideal for connecting your main audio source. Simply connect your cables directly to the unit with XLR or 1/4-inch (6.5mm) or 1/8-inch (3.5mm) Mini TRS or TS (tip and sleeve) cables.

Output Connections

The Nano Patch+ stereo outputs are also located on the rear panel and feature a pair (Left and Right) of TRS 1/4-inch (6.5mm) balanced analog output connectors. Connect these outputs to your speaker system or an audio recorder. Or use the 1/8-inch (3.5mm) Mini TRS jack to connect Nano Patch+ to your sound system.

Volume Attentuation

The Nano Patch rotary control allows precise level adjustments from 0 to -40dB. Produce the required amount of volume by rotating the volume control in a clockwise direction to increase the volume (reduce the amount of attenuation) or counter-clockwise to reduce the volume and increase the amount of attenuation.

Mute Operation

The on/off Mute Switch on the front panel allows engagement of the Nano Patch+ built in mute function. When the Mute Switch is engaged, the Nano Patch+ audio signal output is disabled.

Applications

A versatile problem-solver, you can use the Nano Patch+ anywhere you need to adjust gain; ie, reduce the volume of analog audio signals. For example, use the Nano Patch+ to adjust the output level of a microphone pre-amplifier. With its high-quality potentiometer, the Nano Patch+ delivers pure, clean audio to any receiving device, passes signal more accurately, and sounds better than built-in volume controls.

The Nano Patch really comes into its own when connected between your computer audio interface/soundcard master outputs and a pair of active (powered) monitor speakers. Use of Nano Patch+ eliminates the need to control volumes with your software’s master volume fader. Reducing levels using the volume control in your software may reduce the audio bit depth of the digital signal. It is preferable to set the master level control in your software at the unity gain setting and attenuate the monitor level using Nano Patch+. This way you can maintain maximum audio resolution and be confident the sonic integrity of your audio is not compromised.

Features

Features

  • Super compact 2-channel analog passive volume control
  • Rotary volume attenuation control
  • Mute button
  • Completely transparent operation
  • No power required
  • 2 x combo inputs (balanced and unbalanced)
  • 2 x TRS outputs (balanced and unbalanced)
  • 1 x Mini jack I/O
  • No signal conversion from unbalanced to balanced!
Specification
Input Connectors 12 x Combination XLR/TRS 1/4-inch (6.5mm) balanced/unbalanced
Input Connectors 21 x 1/8 inch (3.5mm) Mini Jack
Maximum Input Level+26dB
Input Impedance5K ohms
Output Connectors 12 x TRS 1/4 inch (6.5mm) balanced/unbalanced
Max Output Level> +26dB
Output Connectors 21 1/8 inch (3.5mm) Mini Jack
Impedance0-5K ohms
Frequency Response0/0.15dB (10Hz - 40KHz)
Signal-To-NoiseBetter than -120dB
Channel Cross Talk> -80dB
Distortion< 0.0004%
Dimensions (H x W x D)2.0" (51 mm) x 5.1" (130 mm) x 3.75" (95 mm)
Weight0.8 lbs (0.34 kg)
