Mackie DL32R 32-Channel Wireless Digital Mixer with iPad Control (Discontinued)
Part # 2045880-00
Model # DL32R

The DL32R delivers 32-channels of powerful digital mixing that’s completely controlled wirelessly from your iPad, freeing you to get in the mix like never before.

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

The DL32R delivers 32-channels of powerful digital mixing that’s completely controlled wirelessly from your iPad, freeing you to get in the mix like never before. It’s got convenient direct-to-drive multi-track recording/playback and an ultra-compact 3U rackmount design that lets you ditch the snake once and for all. Fully loaded with DSP on each of the 32 Onyx+™ mic pres and 28 busses, the DL32R provides the power needed for professional applications. The industry-proven Master Fader™ app delivers extremely intuitive control over everything, including the ability to digitally recall each and every setting for incredibly fast setup. Control everything from anywhere with the Mackie DL32R.

Features

Features

32-Channel Wireless Digital Mixer:

  • 32 Onyx+™ recallable mic pres with wireless control
  • 14 fully-assignable XLR outputs
  • Stereo AES digital output
  • Total recall of all settings
  • 3U rackmount design ready for road or install
  • Card slot for Dante expansion card*

Wireless Mixing:

  • Complete control from your iPad®
  • No set FOH position – mix from anywhere
  • Personal monitor mixing via iPad, iPhone® or iPod touch®
  • Supports iPad Pro® to show more faders, bigger controls and even finer resolution
  • Supports up to 20 separate iOS devices at once
  • Multiple engineers can work from a single mixer
  • Ditch the snake – place the mixer anywhere

Multi-Track Recording & Playback:

  • 32x32 USB 2.0 audio interface for Mac or PC
  • 32x32 recording/playback direct to USB 2.0 hard drive
  • Wireless control over all direct-to-disk recording/playback functions
  • Record the show for later mixdown
  • Play back intermission music, backing tracks and announcements
  • Perform a virtual soundcheck
  • Easy exporting using iOS system sharing
  • Amazing recording interface for the studio
  • Utilize Mac or PC audio plug-ins in a live environment

Fully-Loaded DSP:

  • 36 input channels with 4-band PEQ + HPF, gate and compression
    • 32 stereo-linkable input channels
    • 4 stereo-linkable return channels*
  • 28 output busses with 4-band PEQ + HPF/LPF, 31-band GEQ, comp/limiter, alignment delay and RTA
    • 14 stereo-linkable aux sends
    • 6 stereo-linkable matrix busses
    • 6 stereo-linkable subgroups*
    • Main L/R busses
  • 6 VCAs and 6 mute groups
  • 3 stereo FX processors with dedicated sends and returns
  • Full I/O routing with A/B sources per channel
  • Assignable oscillator including pink/white noise and sine waves
  • Modern and Vintage options per processor

Master Fader Control App:

  • Intuitive and easy to master
  • Fast navigation with view groups and overview
  • Quick setup with tons of factory and user-definable presets
  • Access Limiting allows flexible customization of user interface and prevents unwanted adjustments from other users
  • Export presets, shows and complete system backups via Dropbox, email and more using iOS system sharing
  • Complete offline operation
  • Easy and frequent updates via App Store


* Dante expansion card coming soon (sold separately). Wi-Fi router and iPad required. Wi-Fi router, iPad, iPhone and/or iPod touch not included. Return channels and subgroups feature PEQ and compression.

Wireless Compatibility – DL Series mixers are compatible with iPad Pro, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPad mini 4, iPhone 6, iPhone 5s, iPhone 5, iPhone 5c, iPhone 4s, iPhone 4, iPad Air 2, iPad mini 3, iPad mini 2, iPad Air, iPad mini, iPad (3rd and 4th generation), iPad 2, iPod touch (5th generation).

iPad, iPhone and iPod touch are registered trademarks of Apple Inc., registered in the U.S. and other countries.

Specification
General Digital
Sample Rate48 kHz
A/D/A Bit Depth24-bit
System LatencyAnalog Input > Main Bus > Analog Output: 1.5 ms
0 dBFS Reference+22 dBu
Frequency Response
All Inputs to All Outputs±0, –1 dB, 20 Hz to 20 kHz
Distortion (THD)
Mic input to main output, 1 kHz, –1 dBFS<0.005%
Noise / Dynamic Range / Signal-to-Noise Ratio
Equivalent Input Noise (EIN)150Ω termination: –128 dBu
CrosstalkAnalog XLR input-input: <–105 dB @ 1 kHz (min. gain);
<–80 dB @ 1 kHz (max. gain)
Analog XLR / TRS output-output: <–100 dB @ 1 kHz
Signal-to-Noise Ratio92 dB
Output Noise (A-weighted)Muted Output: –90 dBu
Dynamic RangeAnalog Input to Analog Output
(One channel and main fader at unity, A-weighted): 109 dB
Analog Input
(Unity gain, to analog clipping, –60 dBFS signal, A-weighted): 111 dB
Analog Output
(To analog clipping, –60 dBFS signal, A-weighted): 111 dB
CMRR>70 dB @ 1 kHz (60 dB gain)
Power
Power Requirements100 VAC – 240 VAC, 50 – 60 Hz, Universal Supply
Power Consumption100W max
Line CordUser-replaceable IEC
Operating Temperature0 - 40 °C (extended ambient temperature: 32 - 104 °F)
Dimensions (H x W x D)
Product5.4" (138 mm) x 19" (483 mm) × 17.5" (443 mm)
Shipping8.8" (224 mm) x 21.2" (538 mm) x 21" (533 mm)
Weight
Net18 lbs (8.2 kg)
Shipping23 lbs (10.4 kg)
