- Description
Details
Proportional speed thermostatic fan control extends both equipment and fan life and reduces service calls by varying the fan speed of up to four fans, based on the temperature within the enclosure.
Featuring three temperature ranges, the fan control can be set to activate proportional to the enclosure temperature, or to come on at full power whenever the temperature threshold is reached.
Available to either mount within the company’s MPR Modular Power Raceway or as a standalone unit, the Middle Atlantic Products FC-4 is unique in design, allowing control of up to four 120 volt fans.
The FC-4’s temperature control range can easily be set to trigger automatically at 80°F, 85°F or 90°F. Fans will run at either a speed proportional to the internal temperature or automatically at full speed when the internal temperature reaches the predetermined threshold. In addition to these automatic proportional speed settings, additional settings are available, allowing for continuous fan operation or no operation at all.
Two status LED’s indicate whether the FC-4 is in AUTO or ON mode, with the ON LED blinking in proportion to the fan’s operating speed.
- Features
Features
- Allows fans to operate at speeds proportional to temperature inside of enclosure
- Available as a stand-alone or MPR raceway mounted module
- Can be turned on and off via a local switch
- Status LEDs indicate fan speed setting
- Constructed of 18-gauge steel
- Allows control of up to 4 fans, depending on model
- Available stand-alone with two 15 amp receptacles
- Finished in a durable flat black powder coat
- UL Listed
- Specification
Number of Fan Outlets 2 Amp 15 LED's Indicator Auto or On Mode 2 Status LED's Indicator Construction 18-gauge steel Power Input 120VAC - 60HZ Power output 2 NEMA 1-15R (2 prong) outlets Temperature control range 80°F, 85°F or 90°F Temperature Probe Wire 5 ft. Finish Durable flat black powder coat - Documents
Documents
