- Description
Details
The DT-930 AM/FM Tuner is a frequency-synthesized AM/FM stereo tuner designed to provide broadcast program material for background and foreground music systems. Featuring a clean, uncluttered look with easy and intuitive control, the DT-930 provides outstanding performance and sound quality with superb sensitivity and stability.
A large digital LCD display indicates radio station, memory preset, tuning mode and frequency band. The DT-930 offers 40 memory presets which can be divided as desired between AM and FM stations. The automatic up or down station scan control can be used to select the next preset or frequency. In addition, manual station tuning is also provided using the station up/down tuning bar. Both these tuning methods can be set independently for the AM and FM bands. Alternative selection methods include direct entry of a frequency or memory preset number.
For selecting stations without referring to any frequencies, the DT-930 provides an Automatic Preset Tuning (APT) function which automatically scans from the lowest frequency of the band selected. As it scans, it will automatically enter the first 20 stations it encounters for both the AM and FM bands. The result is automatic programming of all memory presets. Both mono and stereo line outputs are provided, each with an output level of –15dBV into loads of 10k ohm or higher, optimum for driving the line inputs of TOA mixers and amplifiers. Included with the tuner is a 300 ohm FM dipole antenna, AM loop antenna and stereo RCA cable.- Features
Features
- Presets for 40 AM and/or FM stations
- High quality, commercial AM/FM tuner
- Frequency synthesized digital tuning ensures reliable signal reception
- Assignable presets for up to forty AM/FM stations
- Multi-function LCD digital display
- Automatic station scan (local or distant) mode
- Automatic station storage to memory using scan mode
- Manual station selection using up/down keys
- Direct station frequency entry using numeric keys
- Separate stereo (dual RCA) and mono (RCA and screw terminal) outputs
- Stereo: dual RCA pin jacks
- Mono: RCA pin jack and screw terminals
- Includes FM and AM antennas plus stereo RCA cable (40")
- Optional rack-mount kit, model MB-15B (1U)
- Specification
Type AM/FM Synthesized Digital Tuner Power Requirements 120V AC, 60 Hz (supplied from AC adapter) Power Consumption 180 mA (when AC adapter is used) Receiving Frequency FM: 87.9 MHz – 107.9 MHz (200 kHz steps)
AM: 520 kHz – 11710 kHz (10 kHz steps)Antenna Inputs FM: 300 ohms (balanced), 75 ohms (unbalanced)
AM: Loop antenna (balanced), External antennaAudio Output Stereo -15 dBV 10k ohms, unbalanced, RCA jack Monaural -15 dBV, 10k ohms, unbalanced, M3 screw terminal, distance between barriers: 6.4 mm, RCA jack Channels of Memory 40 channels in total for AM and FM broadcasts Operating Temperature 32° to 104° F (0° to 40° C) Finish Panel: Aluminum (hair-line finish), black
Case: Pre-coated steel plate, blackAccessories 1 - AC adapter x 1 - FM antenna x 1 - AM loop antenna x 1 - RCA stereo cord Dimensions (H x W x D) 2.09" (53 mm) x 16.54" (420 mm) x 11.61" (295 mm) Weight 6.17 lbs (2.8 kg) - Documents
