TOA TS 775 Remote Delegate Interface Unit (Discontinued)
Part # TS-775
Model # TS-775
The TOA TS-770 Series Conference System is ideal for conferences and meetings in government, corporate, educational and hotel applications. The new system provides communications for conferences and boardrooms.

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

The TS-770 Series Conference System is ideal for conferences and meetings in government,  corporate, educational and hotel applications. The new system provides communications for conferences and boardrooms. The easy to use TS-770 Series is comprised of the TS-770 Central Unit supporting up to 70 chairperson / delegate stations.

The TOA TS-770 Conference System brings a multiple-mode remote conferencing to the meeting room, via a standard telephone line, a mobile phone, or PC-based IP telephony. It provides a full range of features for ensuring clear sound for efficient and effective conferences, and at a remarkably high cost/performance ratio.

The TS-770 does away with the need for a conference hall with professionally and permanently installed equipment for small-to-medium-sized meetings. Setting up the TS-770 is quick and easy. The basic requirements are simply to attach the Chairman and Delegate Units to the system’s Central Unit, and connect each Delegate Unit, accordingly. Depending on an application, a unit may be farther apart from each other so an optional Extension Cord (2m/10m) can be attached. Up to 70 units, including multiple Chairman Units, may be attached to a single Central Unit (35 per line), and system expansion to 140 or 210 units is possible by adding a 2nd or 3rd extension Central Unit. Operating the TS-770 goes smoothly and efficiently. An optimized unidirectional gooseneck microphone and wide frequency response speaker are included in every participant’s unit, to ensure optimally clear voice transmission, with everyone clearly heard. Simply pushing the Talk button activates the microphone, while also deactivating the speaker in the unit, to prevent howling. The Chairman Unit can select one, three or six Delegate Units for simultaneous operation, and if several Chairman Units are included, they may speak simultaneously. Smooth operation of the conference is assured by a Chairman Unit's priority function.

Features

Features

  • Easy to set up and operate.
  • Telephone or PC Remote Delegate station operation using the TS-775.
  • All Microphones ON Record function.
  • External source inputs and PA/record outputs.
  • System Test function.
  • Audio Input/Output for local PC connection to a remote PC participant:
  • PC to PC call connection over network uses third party software/service not provided by TOA.
  • RJ-11 connection provided to connect with handset connector on telephone base unit for calls connected to a remote telephone participant.
  • Speech Mode (Selectable):
  • Auto: VOX (Voice Activated Switch).
  • Manual: Talk Key On-Off switching function.
  • Contact closure output when microphone is active:
  • Can be used for camera call-up, tally or other devices.
Specification
Power Req35 V DC, under 30 mA (supplied from Central Unit TS-770)
Input–60dB*, 200 ohms, balanced, mini phone jack with VR control
Output–60dB*, 22 ohms, balanced, mini phone jack with VR control
Speech ModeAUTO: Voice-activated Automatic switchingMANUAL: Talk key on-off switching
Connection Cable2m (6.56 ft)
Operating Temperature0°C to 40°C (32°F to 104°F)
Operating HumidityUnder 90 % RH (no condensation)
FinishPre-coated steel plate, black
Weight2.4 lbs
Dimensions160 (W) × 41.8 (H) × 100 (D) mm (6.3" × 1.65" × 3.94") (excluding projection)
