Yamaha VXC4 4" In-Ceiling Loudspeakers - Pair
Part # VXC4
Model # VXC4

The Yamaha VXC4 speaker offers a versatile lineup for clear consistent sound and are designed to accommodate a growing list of applications in the installation market.

Availability: Usually arrives in 5-9 business days.

Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email [email protected] or call us at 888-256-4112.

* Required Fields

Pro Acoustics Price $270.98

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

Yamaha designed the VXC and VXS speakers to accommodate a growing list of applications in the installation market. While these speakers deliver quintessential Yamaha sound quality, they have also been carefully designed for safe and easy installation. Featuring both ceiling and surface mount options, these speaker series include a comprehensive range of models that are available in either black or white, or can be painted to match the interior of any application. Available in Black or White. Sold in pairs.

The VXC4 loudspeaker has a 4-inch woofer, suitable for a wide range of venues. It has an internal transformer that allows both high and low-impedance drive with just a single speaker, simply by switching the tap on the baffle. Since a single speaker can be used for both operations, inventory control is simplified, and you can easily adapt your system to any changes.

Features

Features

  • Full-range loudspeaker with a 4" driver
  • Accommodates a growing list of applications in the installation market
  • Delivers quintessential Yamaha sound quality
  • Carefully designed for safe and easy installation
  • Can be painted to match the interior of any application
  • Available in Black or White
  • Sold in Pairs
Specification
Frequency Range (-10dB)80Hz - 20kHz (Half-space:2π)
Nominal Coverage130° conical (Half-space:2π)
Components (LF-HF)4" full-range
Power Rating
Noise30W
PGM60W
Peak120W
Nominal Impedance
Transformer Taps
70V30W (170Ω), 15W (330Ω), 7.5W (670Ω), 3.8W (1.3kΩ)
100V30W (330Ω), 15W (670Ω), 7.5W (1.3kΩ)
SPL
Sensitivity (1W; 1m on axis)87dB SPL
Peak (Calculated)108dB SPL
I/O Connectors1 x Euroblock (4P) : (Input: + / -, Loop Thru: + / -)
FinishVXC4: Black / VXC4W: White
Cutout SizeØ186 mm (Ø7-5/16")
Required Ceiling Board Thickness5 mm – 35 mm
AccessoriesO-ring, Tile Rail, Cutout Template
PackagingPackaged in pairs
CertificateUL1480, UL2043, NFPA70, CE, EAC, RoHS
Dimensions (Dia x H)8.9" (225 mm) x 7.7" (195 mm)
Net Weight5.7 lbs (2.6 kg)
