Yorkville PGM8 8-Channel Compact Mixer
Part # PGM8
Model # PGM8

The Yorkville PGM8 compact mixer has high-quality 60mm faders throughout, an effective fully featured input channel design, 24-bit digital effects, and a break switch.  It's the perfect mixer for live music applications and for small installs.

Availability: Usually arrives in 5-9 business days.

Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email [email protected] or call us at 888-256-4112.

List Price $615.00
Pro Acoustics Price $439.00
Your Savings $176.00 (29%)
OR

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

The Yorkville PGM8 delivers all of the essential features needed in a professional mixer in a convenient, ultra-compact package. High quality 60mm faders throughout, effective fully featured input channel design, 24-bit digital effects, and break switch make the PGM8 the perfect mixer for live music applications and for small installs.

Features

Features

  • Four Mono Input Channels with XLR & 1/4-inch TRS inputs
  • Channel 4 Mono Input has a Hi-Z input switch
  • Two Additional stereo line input channels (5/6 and 7/8)
  • Additional XLR mono input per stereo channel for maximum 6 Mic inputs
  • Input gain level control with Non-defeatable soft multi-slope compressor on every input
  • 3-band EQ, High Pass Filter, Monitor send , Effect Send, Clip LED, Mute Switch and Pan control per Channel
  • 60mm Faders Throughout
  • Global 48 volt Phantom Power
  • 7-band stereo graphic EQ on Main Outs
  • Stereo RCA Record Outputs with Level Control
  • BREAK Switch (mutes all input channels)
  • Stereo RCA Media Input Jacks with Rotary Level Control (returns pre equalizer, post BREAK switch)
  • Monitor TRS Output
  • Main stereo TRS phone and XLR outputs
  • Sixteen 24-bit digital audio effects
  • Effects TRS output jack
  • Effects defeat footswitch jack
  • Effects return to Main and Monitor
  • Stereo Return TRS jacks with fader
  • Headphone Level Control
  • Stereo Headphone Output Jack (Signal strong enough to drive 8-ohm speakers)
  • Dual 10-segment LED Output Meter
  • IEC removable line cord receptacle (No Adaptors)
  • Universal Power Supply from 90VAC to 264VAC at either 50Hz or 60Hz
Specification
Number of Channels8
Mono Channel EQ3-band
Balance ControlsYes
Pan ControlsYes
Channel Overload ProtectionYes
Inputs - XLR (bal)6
Inputs - 1/4 IN6
Inputs - RCA (unbal)1 stereo pair
Phantom Power48 volt + LED indicator
VU Meter2 x 10 Segment LEDs
Headphone Monitor FeaturesYes
Internal Effects24 bit stereo 16 effects
Effects Send2 (1 internal, 1 external)
Effects Return to MainYes
Effects Return to MonitorYes
Reverb / Effects FootswitchYes
Record Outputs1 stereo pair
Mixer - Signal to Noise Ratio (dB)Greater than -100dB
Mixer - Freq Resp (Tone and EQ Flat,±2dB)20Hz - 20KHz
Mixer THD (Main out w/ -10dB input)Less than 0.05%
Typical crosstalk -1 kHz (dB-Greater Than -60dB
CMRR @ 60Hz (min/typ)55dB/65dB
Power Consumption (typ/max)26VA (typical)
Chassis ConstructionSteel
Dimensions (H x W x D)2.8" (70 mm) x 12.8" (325 mm) x 14.2" (360 mm)
Weight8.5 lbs (3.8 kg)
