MIPRO MTM-92 (5A) UHF Interlinking Transmitter Module for MA-708 and MA-808 Portable PAs

Home /
MIPRO MTM-92 (5A) UHF Interlinking Transmitter Module for MA-708 and MA-808 Portable PAs (Discontinued)

Description

Details

The MIPRO MTM-92 (5A) is an interlinking transmitter module with 16 selectable channels (480MHz to 934MHz), a numeric LED display and modularized design for easy installation and replacement. It fits MA-708 and MA-808 portable PA systems.

Features

Features

16 Selectable channels
Frequency 5A (480MHz to 934MHz)
Numeric LED display
Modularized design allows easy installation and replacement
Fits MA-708 or MA-808 portables

Specification

Frequency Range	UHF 480MHz to 934MHz
Bandwidth	24 MHz
Oscillation Mode	PLL Synthesized
RF Output Power	10 / 100 mW switchable (country dependent)
Spurious Emissions	< -45 dBm
Dimensions (H x W x D)	2.2" (57 mm) x 8.6" (220 mm) x 7.5" (190 mm)
Weight	0.9 lbs (0.41 kg)
