AKG C747 V11 Professional Shotgun Condenser Microphone

Write a Review

Part #:

2226H00110

Model #:

C747 V11

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The AKG C747 V11 is a professional shotgun condenser capsule with a flat frequency response and a clean off-axis response. Due to its brilliant sound reproduction, it is perfect for guitar, piano, drum and overhead recordings.

Description

The C747 V11 is a professional shotgun condenser capsule with a flat frequency response and a clean off-axis response. Due to its brilliant sound reproduction, it is perfect for guitar, piano, drum and overhead recordings. Thanks to its inconspicuous appearance, it is also widely used as a speech and lectern microphone.

The C747 V11 features an integrated RFI shield to block out unwanted interference from mobile phones, wireless microphones and other wireless devices. The C747 V11 ships with an extensive accessory set including a shock mount adapter, mini-gooseneck, stand adapter, mounting clamp, thread link and windscreen.

Features

Enhanced, hypercardioid polar pattern eliminates noise from the sides
RFi shielding technology prevents interference noise from mobile phones
Withstands high sound pressure levels or close-up miking of loud sources
Small and inconspicuous for mobile and installed solutions
Extensive accessory set included for a wide range of mounting possibilities

Specifications

General
Audio Frequency Bandwidth	30 to 18000 Hz
Equivalent Noise Level	32 dB-A
Sensitivity	8.5 mV/Pa
Signal to Noise	73 dB-A
Bass Cut Filter	150 Hz
Electrical Impedance	400 Ohms
Recommended Load Impedance	1500 Ohms
Polar Patterns	Hypercardioid
Powering Interface
Voltage	9 to 52 V
Current	2 mA
Audio Output
Type	Balanced XLR
Gender	Male
Contacts	3-Pin
Design
Finish	Stage Blue
Dimensions (Dia x L)	0.35" (9 mm) x 5.39" (137 mm)
Net Weight	0.055 lbs (0.025 kg)

DOCUMENTS

In The Box

(1) AKG C747 V11
(1) H47 Shock Mount
(1) MSH70 Short Gooseneck
(1) SA47 Stand Adaptor
(1) SHZ80 Screw Link
(1) Windscreen
