AKG DMS800 Mix Set Reference Digital Wireless Microphone System (Discontinued)

Description

Details

The DMS800 Vocal Instrumental Set is a reference digital wireless system available for Band1 that can be used for both vocal and instrumental applications.

The mix set contains the DSR800 reference two-channel digital wireless receiver, the DHT800 handheld transmitter, one D5 WL1 microphone head, the DPT800 body back transmitter, and a C111 LP ear hook microphone.

The DSR800 receiver provides an ultra-wide bandwidth of up to 150MHz for reliable and versatile operation. The DHT800 handheld transmitter delivers durability, easy handling and dependability, while the D5 WL1 dynamic microphone head provides powerful, crisp sound to cut through every mix or deliver on even the noisiest stage. The DPT800 body pack transmitter offers an ultra-wide bandwidth of 150MHz and the convenience of remote programming via infrared data transmission from the DSR800. The set's C111 LP lightweight ear hook microphone combines a comfortable and secure fit with robustness and reliability. Rounding out the set is an SA63 stand adapters for the handheld transmitters and an MKG L instrument cable for use with the DPT800 transmitter.

The DMS800 Vocal Instrumental Set is only available in the U.S.

Features

Features

Now with digital audio outputs DANTE and AES EBU
Interchangeable microphone heads
HiQnet network remote control and monitoring
Digital wireless audio transmission
150 MHz ultrawide frequency range
512-bit encryption

Specification

Frequency Bands	1: 548.1 - 605.9 & 614.1 - 697.9 MHz 2: 710.1 - 785.9 & 823.1 - 831.9 MHz
Switching Bandwidth	Max. 150 MHz (Depending on Frequency Band)
Diversity System	Digital Diversity
Radio Output Power	10 To 50 Mw (Depending on Frequency Band)
Audio Bandwidth	25 – 20 000 Hz (+/- 3dB)
Frequency Selection	Selectable Frequency in 25 kHZ Steps
Switchable RF Power	Yes
Modulation	Digital FSK
Radio Range (Line of Sight)	100 M (Depending on Antenna System)
Encryption	512 Bit
DSR800 Reciever
Rack Size	Full 19" (482.6 mm)
Dimensions (H x W x D)	18.89" (480 mm) x 1.77" (45 mm) x 9.06" (230 mm)
DHT800 Handheld
Dimensions (Dia x L)	46" (37 mm) x 6.69" (170 mm) (w/o Mic Head) 17" (55 mm) x 9.45" (240 mm) (with Mic Head)
DPT800 Body Pack
Dimensions (H x W x D)	3.23" (82 mm) x 2.56" (65 mm) x 1.10" (28 mm) (w/o Antenna) 7.24" (184 mm) x 2.56" (65 mm) x 1.10" (28 mm) (with Antenna)
