Alfatron ALF-CP1L OLED Wall-Mounted DSP Controller

Alfatron ALF-CP1L OLED Wall-Mounted DSP Controller with PoE and IP Control

Name: Alfatron ALF-CP1L OLED Wall-Mounted DSP Controller with PoE and IP Control
Brand: Alfatron
SKU: ALFA-ALF-CP1L
Price: 459.99 USD
Availability: InStock

Write a Review

Part #:

ALF-CP1L

Model #:

ALF-CP1L

Current Stock:

MSRP: $480.00

$459.99

Availability: Usually arrives in 5-9 business days.

Shipping Notice: We are moving! Shipping will be temporarily paused from October 15 to 19 and will resume on October 20.

Quantity:

Adding to cart… The item has been added

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Alfatron ALF-CP1L 1.3" OLED wall-mounted DSP control panel provides customizable control of volume, routing, presets, and more. It features a 2-line OLED display, a rotary encoder with push-to-select, and a single CAT5 network connection for DSP control and PoE power.

Description

Alfatron ALF-CP1L OLED Wall-Mounted DSP Controller

The ALF-CP1L wall-mounted control panel consists of a 1.3" OLED screen and a rotary encoder with Push-to-Select. The 2-line OLED provides customizable menus and sub-menu controls for volume, routing, presets, and more. Easily programmed and managed from the Alfatron DSP software, the control panel provides quick and easy connection to the DSP control network.

The Alfatron ALF-CP1L uses a single CAT5 network connection for both control and power, with PoE providing convenient operation. Its customizable menus and rotary encoder with Push-to-Select allow users to access programmed DSP controls from a wall-mounted location.

Most Alfatron products come with a 7-year limited warranty. Register your product with Alfatron to receive an additional 3-year extended warranty on eligible products, for 10 years of total coverage.

Features

2-line OLED display
Quick and easy connection to your DSP control network
Easily programmed from the Alfatron DSP software interface
Customized menus
Rotary encoder with Push-to-Select
Single network connection
PoE powered
7-Year limited warranty + 3 additional years with registration

Specifications

Button Type	Rotary Encoder with Push to Select
Connection	Ethernet
Connection Type	RJ45
Volume Control	Yes
Preset Recall	Yes
Button Control	Yes
External Commands	Yes
Matrix	Yes
PoE Power Requirements	PoE
Maximum Power Consumption	100 mW
Operating Temperature	0 - 40°C
Screen Type	OLED
Screen Size	29.5 mm x 14.5 mm
Weight	0.88 lbs (0.4 kg)
