Anchor Audio Beacon 3 Pro Portable Battery Powered Line Array PA System with Bluetooth, AnchorLink, AnchorFlex, and Wireless Handheld Microphone
Usually arrives in 5-9 business days.
The Anchor Audio Beacon 3 Base is a compact, battery-powered portable PA system designed for reliable, clear sound in classrooms, small events, and basic sound reinforcement settings. Its simple, portable design makes it ideal for users who need effective audio without the complexity of advanced wireless features.
This system includes one BEA3 Beacon 3 Base portable line array speaker with standard audio inputs, allowing connection to microphones, instruments, or audio devices. With three 8-inch neodymium woofers and six high-output tweeters, this speaker delivers balanced, intelligible sound for small to medium-sized audiences. Integrated Bluetooth provides easy wireless streaming from smartphones, tablets, or laptops. This package also includes a MIC-90 wired handheld microphone, ready for immediate use.
Designed for portability, the Beacon 3 Base features a telescoping speaker array that collapses to just 28 inches for transport and extends to 72 inches for optimal sound projection. Built-in wheels and an integrated handle make setup and transport effortless, while the rugged, weather-resistant enclosure ensures reliable performance in a variety of environments. Its rechargeable battery provides extended operation for outdoor or mobile applications without requiring an AC outlet.
Reliable, portable sound with Bluetooth and wired mic for basic, effective audio reinforcement.
Important operating information: The Beacon 3 Base is specified for operation at altitudes up to 2,000 meters (approximately 6,562 feet). Operation above this altitude is outside the manufacturer's specified operating range and may affect cooling, thermal performance, electrical safety margins, and overall system reliability. Normal performance and reliability cannot be guaranteed above the specified altitude limit.
| Rated Power Output | 200 Watts thru RMS |
|---|---|
| Max SPL @ Rated Power | 123 dB @ 1 meter |
| Frequency Response | 60 Hz - 15 kHz ± 3 dB |
| AC Power Input | 100 - 240V~AC, 50-60 Hz, 3.1A |
| Line Inputs | Unbalanced 1/4" & 3.5 mm stereo |
| USB (Charging Only) | 5V/2.5 Watts |
| Battery | Two 12.8V rechargeable, 10.2 Ah (LiFePO4 Lithium Iron Phosphate Battery) Full Recharge: approx. 5 hrs |
| Flex Radio | 1.9 GHz DECT 6.0 or EU-DECT ≈ 300' line of sight |
| Bluetooth | 2.5 GHz ≈ 60' line of sight |
| Microphone Inputs | Lo-Z, balanced, XLR 36VDC condenser mic (phantom) power |
| Microphone Wireless Frequency | 1.9 GHz DECT 6.0 or EU-DECT ≈ 300' line of sight |
| Line Inputs | Unbalanced 3.5 mm stereo & Balanced 1/4" |
| Line Output | PreFader, isolated, 600Ω, 1/4" phone |
| Speakers | Three, 8" Woofer, Neodymium Magnet, 6 ohms Eighth,4" Midrange driver, Neodymium Magnet, 8 ohms |
| Compliance | BT FCC ID: 2AMWO-FSCBT1026/IC ID: 23872-FSCBT1026 WAM DECT Radio FCC ID: Y82-SC14S / IC ID: 9576A-SC14S, RoHS3 |
| Dimensions (H x W x D) | Opened: 72" (1828.8 mm) x 11" (280 mm) x 18.5" (470 mm) Closed: 28" (711.2 mm) x 11" (280 mm) x 18.5" (470 mm) |
| Weight | 51 lbs (23 kg) |
