Anchor Audio BIG3 Bigfoot 3 Line Array Portable PA System with Bluetooth (Discontinued)

Anchor Audio BIG3 Bigfoot 3 Line Array Battery-Powered PA System with Bluetooth

The BIG3 Bigfoot 3 Basic is a powerful, self-contained portable PA system engineered for reliable use in both indoor and outdoor environments. Built to dominate large crowds, it delivers 300W of power through a rugged line-array design featuring five 8" neodymium woofers and a high-efficiency compression driver, producing peak sound levels up to 126 dB. It provides coverage over approximately a 150 x 150 ft area, suitable for up to 2,500 people, depending on the space and acoustics.

This system runs on three internal 12V LiFePO₄ rechargeable batteries, offering over 7 hours of continuous use on a full charge, with a recharge time of approximately 5 hours using standard AC power (100–240V, 50/60Hz).

Connectivity includes:

• Class 1 Bluetooth with up to 150 ft range for wireless audio streaming
• Two balanced XLR/¼" combo mic inputs with 48V phantom power (wired microphones only)
• One ¼" line input (Hi-Z compatible)
• One 3.5 mm stereo aux input
• One ¼" line output (pre-fader, isolated, 600Ω) for daisy-chaining to additional systems
• USB charging port (5V/500mA) for mobile devices

The BIG3 is designed for one-person setup, with a folding tower array that extends to 72" when open and collapses to 42.5" for transport. Its durable, weather-resistant enclosure includes built-in heavy-duty wheels, making it easy to move between venues.

Note: This base BIG3 model does not support wireless microphones and does not include built-in wireless mic receivers. Wireless microphones cannot be added to this model. For wireless capability, see BIG3 models with built-in AnchorLink receivers (e.g., BIG3-TU4, BIG3-U4).

Made in the USA and backed by Anchor Audio's industry-leading 6-4-2 warranty: 6 years for the speaker, 4 years for the batteries, and 2 years for microphones and accessories.

Mics not included. Capable of accommodating audiences of up to 2,500 depending on the environment and specific application.

• 300W RMS Class-D amplifier with peak sound output up to 126 dB
• Five 8" neodymium woofers and one high-efficiency compression driver in a vertical line array
• Class 1 Bluetooth with up to 150 ft wireless streaming range
• Two XLR/¼" combo mic inputs with 48V phantom power (wired mics only)
• One ¼" line input (Hi-Z compatible)
• One 3.5 mm stereo line input
• One ¼" line output (pre-fader, isolated, 600Ω) for daisy-chaining
• USB charging port for mobile devices (5V/500mA)
• Three 12V rechargeable LiFePO₄ batteries provide over 7 hours of runtime
• Rapid AC charging (100–240V, 50/60Hz); full recharge in approximately 5 hours
• Foldable line array tower design: 72" (1829 mm) open, 42.5" (1080 mm) closed
• Durable, weather-resistant enclosure with built-in heavy-duty wheels
• Coverage area: approximately 150 x 150 ft; ideal for up to 2,500 people
• Made in the USA
• Backed by Anchor Audio's 6-year speaker, 4-year battery warranty
