Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.The all-purpose REVAMP4100 is a professional digital 4-channel power amplifier delivering 4 x 100 watts of output power at 4 ohms, with support for 70V and 100V distributed audio systems. Each of the four independent amplifier channels can be bridged into two higher-power channels, offering flexible configuration options for a wide range of installation requirements. This Class D amplifier features advanced speaker and amplifier protection circuits, including DC protection, over-current protection, over-temperature protection, and input overload protection to ensure reliable long-term operation. Designed for professional environments, the REVAMP4100 provides efficient, high-performance amplification in a compact form factor, making it ideal for commercial and installed sound applications.
| Dynamic Output Power at 4 Ohms | 4 x 110W |
|---|---|
| Output Power RMS at 4 Ohms | 4 x 100W |
| Output Power RMS at 8 Ohms | 4 x 50W |
| Minimum Load Impedance | 4 ohms 8 ohms in bridged mode |
| Line Inputs | Balanced: 4 on euroblock Unbalanced: 8 (4 x cinch with pass-through) |
| Input Sensitivity | 0 dBV / 1 V RMS |
| Input Impedance | 22 kohms |
| S/N Ratio | >98 dB A-weighted |
| Frequency Response | 20 - 22 kHz +0 / -3 dB |
| Protection Circuits | Over current Over temperature DC offset |
| Channel Separation | > 65 dB @ 1 kHz |
| Power Amp Topology | Class-D |
| Power Supply | SMPS |
| Cooling System | Convectional |
| Max Power Consumption | 500 watts |
| Operating Temperature Range | 0 to 35°C |
| Mains Operating Voltage | 100 - 240 V~ 50/60 Hz |
| Dimensions (H x W x D) | 1.73" (44 mm) x 19" (483 mm) x 9.41" (239 mm) |
| Weight | 7.72 lbs (3.5 kg) |
| Shipping Weight | 12.13 lbs (5.5 kg) |
