The Ashly TM-360 is a 3-input, 60 watt unit that offers input and output flexibility coupled with energy efficiency. It uses a Class-D amplifier topology for added energy efficiency.

Description

The Ashly TM-360 is a 3-input, 60W unit that offers input and output flexibility coupled with energy efficiency. It uses a Class-D amplifier topology for added energy efficiency.

A front panel 3.5 mm TRS mini-jack makes it easy to plug-in a back-up music source, such as an mp3 player. Rear panel DIP switches allow you to select the mix going to each zone. There are 2 separate zone outputs: a 1W output for driving a remote speaker, and a preamp output that can be used to drive a separate amplifier.

The TM-360 automatically switches into a stand-by mode if no audio input is received for 25 minutes, thus reducing the current draw. The transformer-isolated output offers a choice of lo-z (4 Ohm), 25V or 70V.

Features

One balanced mic/line input with phantom power, 2 balanced line level inputs with stereo RCA sum-to-mono inputs
Mute priority of inputs
Manual mute contact closure
Mini-jack input on front panel overrides channel 2-input on back
DIP switches for zone 2 assign vox trigger, mute priority, low-cut filter, phantom power
600 Ohm pre-out for external amplifier
Zone 2-output, 1W / 8 Ohms, Balanced 600 Ohm
Power saving standby mode: audio inactivity or contact closure
Optional rack mount kit (model RMK-360)
Safety/Compliance: cCSAus, CE FCC, RoHS

Specifications

Channels	3
Signal-to-Noise (26dB Gain)	80dB
Max Output Power (1% THD)	4 Ohms: 60W 8 Ohms: 30W
Constant Voltage Power (1% THD)	25V: 60W 70V: 60W
Line Current Draw (120VAC 60Hz)	Standby Mode: 0.15A Idle: 0.24A Typical (1/8 power pink noise: 0.38A Max (1/3 power sine wave: 0.66A
Thermal Dissipation (BTU/hr)	Standby Mode: 26 Idle: 43 Typical (1/8 power pink noise: 53 Max (1/3 power sine wave: 75
Operating Temp	40˚F~120˚F (4˚~49˚C), noncondensing
Tone Control	Bass (100Hz) ±10dB, Treble (10kHz) ±10dB
Input Sensitivity	Input 1: -10dBV to -50dBV Input 2, 3: 0dBV to -20dBV
Frequency Response (1W @ 1kHz)	+1/-3dB, 80Hz–15kHz (all inputs)
Dimensions (H x W x D)	3" (76 mm) x 11.4" (290 mm) x 7.3" (185 mm)
Weight	6.7 lbs (3.04 kg)
Shipping Weight	9 lbs (4 kg)
