AtlasIED IED1522AIOLR CobraNet Audio I/O Module with Logic and Relays

Inputs:

• Two balanced analog microphone/line inputs
• Software adjustable, non-volatile, input levels from –50 to +24dBu
• -90dB THD+ N
• Software selectable 48V phantom power individually available on all inputs

Outputs:

• Two balanced analog line outputs
• Software adjustable, non-volatile output levels from -10 tp +24dBu

GPIO:

• Four opto-isolated inputs
• Four normally open relay isolated outputs

CobraNet:

• Redundant CobraNet
• Separate CobraNet channels of CobraNet channels used for in and out

DSP:

• Programmable delay up to 10 seconds on each audio output
• 5 band parametric equalizer bands (high-pass, low-pass, peaking, notch)
• Compander/Limiter on each input
• Level control

Power:

• Power over Ethernet (PoE) 802.3af compliant on primary Ethernet connection
