Atlas Sound IHVP+ Vandal and Weather Resistant IP Loudspeaker (Discontinued)

Part #:
IHVP+
Model #:
IHVP+
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Atlas Sound IHVP+ is a replacement for the Discontinued Atlas Sound IHVP.  The Atlas Sound IHVP+ is a vandal proof, weather resistant, wall mount IP loudspeaker. It leverages VoIP communication to extend tele-presence with enhanced audio for environments where network-wide communication is desired.

Description

The Atlas Sound IHVP+ is a replacement for the Discontinued Atlas Sound IHVP.

The Atlas IHVP+ is a vandal proof, weather resistant, wall mount IP loudspeaker. It leverages VoIP communication to extend tele-presence with enhanced audio for environments where network-wide communication is desired and high-output loudspeakers are required to overcome high ambient noise and/or large spaces. The loudspeaker grills are vandal and weather resistant. Manufactured of cast aluminum alloy, the grills provide security and durability in indoor and outdoor applications.

Atlas  IHVP+ registers as a communication endpoint directly within InformaCast, GCK, and SA-Announce Advanced Notification applications, supporting audio broadcast to enhance physical security while improving day-to-day communications through advanced alerting, bell schedules, pre-recorded & scheduled announcements, while leveraging the WAN/ LAN Network Architecture.

When used within a Cisco Environment, the  IHVP+ loudspeakers can join Cisco’s Unified Survivable Remote Site Telephony (SRST) as a supported device. Cisco’s SRST provides remote location call-processing redundancy when access to the centralized Cisco Unified Communications Manager is interrupted because of a WAN outage. The ability of LAN communication between any combination of phones and loudspeakers is particularly critical during an emergency (which may be the actual cause of the WAN outage).

Where 3rd party notification applications are not required, the  IHVP+ vandal proof, weather resistant, wall mount IP can register as SIP devices directly to a SIP server or VoIP Communications Manager for critical alerts and public address applications.

Ideal for Corporate Applications, Education Institutions, Entertainment Complexes, Industrial Facilities, Government Buildings, Healthcare Facilities, Houses of Worship, Transportation Hubs - anywhere critical alerts / public address needs exist, and prefer using a single enterprise-class communications platform.

Features

Network:

  • Dynamic or Static IP Address
  • IEEE 802.3 10/100Base-T Ethernet
  • IEEE 802.1q Tagging
  • IEEE 802.11AT Compliant
  • VoIP Standard Audio: G.711 u-law/a-law (64 kbit/s) or G.729 Wideband Audio (64 kbit/s)
  • Auto Provisioning: DHCP Option 66, 150, or TFTP Server or DHCP Option 72 for HTTP Server
  • Auto Registration: SLP for InformaCast or DHCP Option 72 for SA-Announce or GCK
  • Static Configuration: HTTP GUI for Static Configuration or Cisco SRST

Audio:

  • Integrated Amplifier 15-Watt Total Power: Primary Speaker Output 8 ohm
  • Aux Audio Line-In Unbalanced (2.8Vpp 10K)
  • Aux Audio Line-Out Unbalanced (2.8Vpp 10K)

Additional:

  • 2 General Purpose Inputs
  • 1 General Purpose Output (2A @ 30 VDC)
  • Phone/Night Loud Ringer
  • External Power Supply Option

Specifications

ConnectorType RJ-45
Safety Listed 60950-1
Dimensions (H x W x D) 10.75" (273.05 mm) x 10.75" (273.05 mm) x 4.875" (123.19 mm)
Shipping Weight 5.50 lbs (2.49 kg)
