Audio-Technica AEW-T6100a Handheld Microphone/Transmitter with Hypercardioid Dynamic Element (Discontinued)

The AEW-T6100a hypercardioid dynamic wireless handheld transmitter features the Artist Elite® AE6100 hypercardioid capsule created for live sound venues. With a polar pattern tailored for outstanding on-axis response, high output, fast transients and clean articulation, the capsule offers maximum feedback rejection and superior anti-shock engineering for low handling noise. An integral two- stage pop filter within the rugged steel headcase protects against “p” pops and other breath plosives. All transmitter setup functions are menu-driven via soft-touch controls. To prevent accidental changes, the controls are covered by the transmitter's handle case when not being used. A dual-color power/mute indicator LED provides visual indication of transmitter status.

Operating on two standard AA batteries, the transmitter features high and low-level RF output settings. The low-level setting allows two additional hours of battery life while retaining a strong RF signal link. Each transmitter's backlit LCD display presents a great deal of setup and operating information clearly and conveniently including: battery fuel remaining, mute, and operating frequency. A flashing “Lo-Batt” alert visually signals the battery life is almost depleted. Programmable power/ mute locks limit the functioning of the transmitter's power/mute button as desired for particular users and applications. To match the audio input level to the transmitter, a four-position audio input gain setting selected through the function menu is provided. Four nameable user presets allow for storage and recall of commonly used settings. The rugged ergonomic metal body housing with integral antenna will provide years of dependable operation. Each handheld transmitter includes a heavy-duty Quiet-Flex™ stand clamp and a soft protective pouch.

• Artist Elite® AE6100 hypercardioid dynamic capsule with integral shock mount
• 996 selectable frequencies in either the 541.500–566.375 MHz or 655.500–680.375 MHz band
• 25 kHz frequency spacing makes it easier to find a clear, open frequency in crowded RF environments
• Two-stage pop filter to protect against “p” pops
• Dual output power selection to optimize battery life
• Digital Tone Lock™ squelch to identify the wireless transmitter to the receiver
• High efficiency dual companding system for flawless audio
• Function menu displayed in a backlit LCD window and controlled by internal touch switches
• Four namable user presets
• Operates on two AA batteries
• Battery fuel gauge LCD readout on the body of the microphone
• Power/mute lock provision
• Dual-color power/mute status indictor
• 18 dB audio input level adjustment
• Rugged metal housing with integral antenna
• Supplied with a heavy-duty microphone stand clamp

AEW-T6100a Submittal Sheet

• (1) AEW-T6100a Handheld Microphone/Transmitter
• (1) AT8456a Quiet-Flex™ Stand Clamp
• (1) AT-BG2 Pouch
