The large-diaphragm Audio-Technica AT4050 exhibits a remarkable combination of qualities: high-SPL capability with transparent and airy uppers/mids complemented by rich low-end qualities.

Description

Audio-Technica AT4050 Multi-Pattern Condenser Microphone

Meet the studio condenser that captures every nuance. With three switchable polar patterns, the large-diaphragm Audio-Technica AT4050 exhibits a remarkable combination of qualities: high-SPL capability with transparent and airy uppers/mids complemented by rich low-end qualities. Its dual large diaphragms are gold-vaporized and aged for consistent, outstanding performance. A precision-machined, nickel-plated brass acoustic element baffle provides rock-solid element stability and exceptional sensitivity.

Features

Transparent uppers/mids balanced by rich low-end qualities combine with advanced acoustic engineering for extensive performance capabilities and highest quality
Dual-diaphragm capsule design maintains precise polar pattern definition across the full frequency range of the microphone
The 2-micron-thick, vapor-deposited gold diaphragms undergo a five-step aging process so that the optimum characteristics achieved remain constant over years of use
Three switchable polar patterns: omni, cardioid, figure-of-eight
Transformerless circuitry virtually eliminates low-frequency distortion and provides superior correlation of high-speed transients
State-of-the-art surface-mount electronics ensure compliance with A-T's stringent consistency and reliability standards
Switchable 80 Hz hi-pass filter and 10 dB pad
Custom shock mount provides superior isolation

Specifications

Element	Externally-Polarized (DC Bias) Condenser
Polar Patterns	Cardioid, Omnidirectional and Figure-of-Eight
Frequency Response	20 - 18,000 Hz
Low Frequency Roll-Off	80 Hz, 12 dB/Octave
Open Circuit Sensitivity	-36 dB (15.8 mV), re 1V at 1 Pa
Impedance	100 ohms
Maximum Input Sound Level	149 dB SPL, 1 kHz at 1% T.H.D 159 dB SPL, with 10 dB Pad (Nominal)
Noise	17 dB
Dynamic Range (Typical)	132 dB, 1 kHz at Max SPL
Signal-To-Noise Ratio	77 dB, 1 kHz at 1 Pa
Phantom Power Requirements	48V DC, 4.2 mA Typical
Switches	Polar Selection; Flat, Roll-Off and 10 dB Pad (Nominal)
Output Connectors	Integral 3-Pin XLRM-type
Accessories Furnished	AT8449 Shock Mount for 5/8"-27 Threaded Stands; Microphone Dust Cover; Protective Carrying Case
Audio-Technica Case Style	R1
Dimensions (Dia x L)	2.10" (53.4 mm) x 7.40" (188 mm)
Weight	1.125 lbs (0.510 kg)

DOCUMENTS

In The Box

(1) AT8449 Shock Mount for 5/8"-27 Threaded Stands
(1) Microphone Dust Cover
(1) Protective Carrying Case
