The ATW-T1006 boundary microphone/transmitter pairs with any System 10 or System 10 PRO digital wireless receiver to provide rock-solid, 2.4 GHz wireless performance.

Description

The ATW-T1006 boundary microphone/transmitter pairs with any System 10 or System 10 PRO digital wireless receiver to provide rock-solid, 2.4 GHz wireless performance with clear, natural sound quality. This cardioid condenser is equipped with a touch-sensitive user switch for talk/mute toggling, two red/green LED indicators, gain control, low-cut filter and a rechargeable 3.7V lithium-ion battery.

Features
  • Cardioid condenser boundary microphone/transmitter pairs with any System 10 or System 10 PRO digital wireless receiver
  • Digital 24-bit/48 kHz wireless operation for ultimate sound quality and dependable performance
  • Operates in the 2.4 GHz range – completely free from TV interference
  • User switch can be set to toggle between talk and mute modes, or function as a press-to-talk or press-to-mute button
  • Gain Control switch allows selection of three input gain levels: -6 dB (for loudest voices), 0 dB and +6 dB (for softest voices)
  • Two red/green LEDs – one visible from the front of the unit, the other from the rear – indicate toggle/talk/mute mode, battery level, and charging status
  • Switchable low-cut filter
  • System ID Display located on bottom of unit
  • Automatic frequency selection for seamless, interference free operation

Specifications
Operating Frequencies 2.4 GHz ISM band
Total Harmonic Distortion
Operating Temperature Range 0° C to +40° C (32° F to 104° F)
Charging Temperature Range 5˚C to + 35˚C
Frequency Response 20 Hz to 20 kHz
Audio Sampling 24 bit / 48 kHz
Maximum Input Sound Level 139 dB SPL
RF Power Output 10 mW
Spurious Emissions Following federal and national regulations
Power Supply 100-240V AC (50/60 Hz) to 5V DC 0.5A switched mode external USB-type power supply
Internal Battery 3.7 V Rechargeable Li-ion Battery
Battery Life 9 hours
Battery Charging Time 4 hours 30 minutes
Accessory Included AC adapter (USB-type), USB cable
Dimensions (H x W x D) 1.5" (38 mm) x 3.78" (96.1 mmm) x 4.83" (122.8 mm)
Weight 0.90 lbs (0.41 kg)
!
