The Audio-Technica ATW-T210b UniPak transmitter is a lightweight bodypack microphone transmitter that operates on the same frequencies as the receiver. The transmitter features a 4-pin Hirose connection input that is compatible with Audio-Technica "CW" lavaliers and headworn microphones, and select instrument cables. The transmitter operates up to 9 hours on two 1.5V AA batteries.
| RF Power Output (50 ohms) | High: 30 mW Low: 10 mW |
|---|---|
| Spurious Emissions | According to National Regulations |
| Input Connections | Four-pin locking connector Pin 1: GND Pin 2: INST INPUT PIN 3: MIC INPUT PIN 4: DC BIAS +9V |
| Battery Type | 2 x 1.5V AA Alkaline or rechargeable AA NiMH (not included) |
| Battery Life | Approximately 9 hours (low), 7 hours (high) |
| Dimensions (H x W x D) | 3.63" (92.3 mm) x 2.60" (66 mm) x 0.89" (22.5 mm) |
| Net Weight (without batteries) | 0.18 lbs (0.08 kg) |
