The versatile ATW-T310b UniPak™ body-pack transmitter has both low- and high-impedance inputs plus a bias connection, for use with dynamic and electret condenser microphones, as well as Hi-Z instrument pickups. In addition to its programmable functions, the transmitter features a three-position sliding cover to limit access, if desired, to just the Power/Mute button, or to cover all the controls, as appropriate for the application and user.- Features
Features
- Band C: 541.500 MHz to 566.375 MHz.
- Dual-impedance input.
- Spurious Emissions: Under federal regulations.
- Antenna Tip Color: Blue.
- Current Consumption: High: 200 mA; Low: 150 mA, typical.
- Specification
RF Power Output High: 30 mW, Low: 10 mW (switchable), at 50 ohms Spurious Emissions Following federal and national regulations Input Connection Four-pin Locking ConnectorPin 1: GNDPin 2: INST INPUTPin 3: MIC INPUTPin 4: DC BIAS +5V Batteries Two 1.5V AA, not included Battery Life High: 6 hours (alkaline)Low: 8 hours (alkaline) Dimensions (W x H x D) 66.0 mm (2.60") x24.0 mm (0.94") x87.0 mm (3.43") Net Weight 1 lbs ( 80g ) - Reviews
