Biamp Nexia VC Digital Signal Processor (Discontinued)

Description

Details

The Nexia VC is a digital signal processor with 8 wide-band AEC mic/line inputs, 2 standard mic/line inputs, 4 mic/line outputs, and a codec interface. Intended for a variety of videoconferencing applications, Nexia VC uses Biamp’s Sona™ AEC technology for more natural sound and full-duplex transmission of speech. Nexia VC includes a broad selection of audio components, routing options, and signal processing. The internal system design is completely user definable via PC software, and can be controlled via daVinci™ software screens, RS-232 control systems, and a variety of optional remote controls. Multi-unit Nexia systems can be created utilizing Ethernet and NexLink digital audio linking.

Features

Features

8 wide-band AEC balanced mic/line inputs
2 standard balanced mic/line inputs
4 balanced mic/line outputs
Codec interface with balanced line input & output
Ethernet port for software configuration/control
Serial port for third-party RS-232 remote control
NexLink ports for multi-unit system designs
Nexia software for Windows®
Pre-configured I/O with definable processing
CE marked, UL listed and RoHS compliant
Covered by Biamp Systems’ 5-year warranty

Specification

Frequency Response (20 Hz~20k Hz @ +4 dBu)	+0/-0.4dB
THD +N (20 Hz~20k Hz @ +4 dBu)	Line level: < 0.006% Mic level: < 0.05%
EIN (20Hz~20kHz, 66dB Gain, 150Ω)	-125dBu
Dynamic Range (20 Hz~20k Hz, 0 dB)	> 105 dB
Tail Length	Up to 300ms
Convergence	Up to 100dB/sec
Input Impedance (Balanced)	Mic/Line Inputs: 8kΩ Codec: 15kΩ
Maximum Input	+24 dBu
Input Gain Range (Variable)	Mic/Line Inputs: 0 - 66dB Codec: 0 - 18dB
Output Impedance (Balanced)	200Ω
Maximum Output	+24 dBu
Full Scale Output Level (Six Selections)	-31dBu ~ +24dBu
Sampling Rate	48k Hz
A/D - D/A Converters	24-bit
Power Consumption	65W
Dimensions (H x W x D)	1.75" (45 mm) x 19" (483 mm) x 11.2" (283 mm)
Weight	8.6 lbs (3.9 kg)
