- Description
Details
Biamp Parlé TCM-1 AVB Ceiling Microphone - Black
The Parlé TCM-1 is an AVB pendant microphone and plenum box. Each microphone includes Beamtracking technology with three 120-degree zones, providing full 360-degree coverage of the meeting space. The plenum box is equipped with an additional RJ-45 connector for daisy-chain connections; a maximum of three microphones are permitted per daisy chain (one TCM-1 or TCM-1A required, plus up to two TCM-1EX).
The Parlé TCM-1 Black complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.
- Features
Features
- Beamtracking technology actively tracks and intelligently mixes conversations
- Three 120-degree zones for 360-degree coverage
- Plenum box includes DSP for Beamtracking
- LED mute status indicator
- User-adjustable microphone height
- Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces
- Pendant microphone available in either white or black
- Optional tile bridge mounting accessory available
- Additional RJ-45 for daisy-chain connection to a TCM-1EX microphone (maximum of three microphones per daisy chain)
- CE marked, UL listed, and RoHS compliant
- 5-year warranty
- Compliant with the US Trade Agreement Act (TAA)
- Specification
Pendant Microphone Microphone Technology 8-Element Digital Array Frequency Response ± 3 dB (150 Hz - 16 kHz Sensitivity > 70 dB (94 dB SPL, 1 kHz) Maximum SPL 106 dB (at 0.5% THD) Polar Pattern Beamformed Dynamic Range 92 dB, A-Weighted (THD+N < 10%) Indicators Mute Indicator (Green/Red LED) Dimensions (H x W x D) 2" (51 mm) x 2.5" (63 mm) x 2.5" (63 mm) Weight 0.4 lbs (0.2 kg) Plenum Box Power PoE (IEEE 802.3at Class 3, 15.4W) Indicators Power Indicator (Green/Yellow/Red LED) Digital Interface Custom/Proprietary Compliance FCC Part 15B (USA)
CE marked (Europe)
UL and C-UL listed (USA and Canada)
RoHS Directive (Europe)
Evaluated to the requirements of UL 2043 and is suitable for use in air handling spacesDimensions (H x W x D) 2" (51 mm) x 7" (178 mm) x 7.125" (181 mm) Weight 2.4 lbs (1.1 kg) - Documents
Documents
