Biamp Tesira EX-OUT 4-Channel Half-Rack Output Expander

The Tesira EX-OUT is a half-rack expander box for use with AVB-enabled Tesira server-class devices. The EX-OUT is a 4-channel mic or line level audio output expander. The expander communicates with the Tesira AVB network for audio networking, configuration, and control, and is powered by PoE+.

The Tesira EX-OUT complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.

Features

Features

Four channels of balanced microphone or line level output
-100 to +12 dB fader range for level
Signal invert for reverse polarity
Selectable full scale output reference level (24 dBu, 18 dBu, 12 dBu, 6 dBu, 0 dBu, -31 dBu) for best interface/performance
Audio and control networking over AVB/TSN
Powered by PoE+
Plug-in barrier strip connectors
Front panel LEDs for device status indications
Half-rack chassis
RoHS compliant and AES grounded
5-year warranty
Compliant with the US Trade Agreement Act (TAA)

Specification

Ambient Operating Temperature Range	32 - 104° F (0 - 40° C)
Humidity	0-95% relative humidity (non-condensing)
Altitude	0-10,000 ft (0-3000 m) MSL
Power	PoE+ (IEEE 802.3at Class 4, 30W)
Phantom Power	+48 VDC (7 mA/input)
Impedance (balanced)	8 kΩ
Input Gain Range	0 - 66 dB (6 dB Steps)
Maximum Input	+24 dBu
Output Impedance (balanced)	200 Ω
Maximum Output	+24 dBu
THD+N	(20 Hz~20 kHz): @ 0 dB Gain, +4 dBu In: < 0.006% @ 54 dB Gain, -50 dBu In: < 0.040%
Frequency Response	(20 Hz~20 kHz @ +4 dBu): +0/-0.25 dB
EIN	(20 Hz~20 kHz, 66 dB Gain, 150 Ω):* < -125 dBu
Dynamic Range	(20 Hz~20 kHz, 0 dB): > 108 dB
Crosstalk	(channel to channel @ 1 kHz): @ 0 dB Gain, +4 dBu In: < -85 dB @ 54 dB Gain, -50 dBu In: < -75 dB
Sampling Rate	48 kHz
A/D Converters	A/D - D/A Converters: 24-bit
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Dimensions (H x W x D)	1.75" (44 mm) x 8.5" (216 mm) x 7.75" (197 mm)
Weight	3 lbs (1.4 kg)
