Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.The TesiraFORTÉ AVB AI is a digital audio server with 12 analog inputs and 8 analog outputs, and up to 8 channels of configurable USB audio. TesiraFORTÉ AVB AI utilizes AVB/TSN digital audio networking, and can be used as a standalone device or combined with other TesiraFORTÉ AVB devices and Tesira servers, expanders, endpoints, and controllers.
| Frequency Response | 20 Hz to 20 kHz, +4 dBu output: +0.25 dB/-0.5 dB |
|---|---|
| THD+N (22Hz to 22kHz) | (22 Hz to 22 kHz): 0 dB gain, +4 dBu input: < 0.006% 54 dB gain, -50 dBu input: < 0.040% |
| EIN | < -125 dBu (no weighting, 22 Hz to 22 kHz): |
| Dynamic Range | 22Hz to 22kHz, 0dB gain: > 108dB (in presence of signal): |
| Input Impedance | 8kΩ (Balanced) |
| Output Impedance | 207Ω (Balanced) |
| Maximum Input | +24 dBu |
| Maximum Output (Selectable) | +24 dBu, +18 dBu, +12 dBu, +6 dBu, 0 dBu, -31 dBu |
| Input Gain Range (6dB Steps) | 0-66 dB |
| Phantom Power | +48VDC (7mA/input) |
| Crosstalk, Channel to Channel, 1kHz | 0 dB gain, +4 dBu input: < -85 dB 54 dB gain, -50 dBu input: < -75 dB |
| Sampling Rate | 48 kHz |
| A/D – D/A Converters | 24-bit |
| Power Consumption | < 35W (100-240VAC 50/60 Hz) |
| USB | Bit Depth: 16- or 24-bit Number of Channels: up to 8 Sample Rate: 48kHz |
| Dimensions (H x W x D) | 1.75" (44 mm) x 19" (483 mm) x 10.5" (267 mm) |
| Weight | 8 lbs (3.63 kg) |
