The Bosch LB20 series is the latest member of the Bosch family of Commercial Loudspeakers for indoor and outdoor applications. Acoustically matched and aesthetically compatible with other Bosch models, the LB20 series incorporates innovative features that efficiently and effectively address the real-world needs of both the installer and the end-user - easy installation and exceptional Bosch audio performance in an incredibly versatile format.

Description

Bosch LB20-PC60EW-5L Extreme Weather 70/100V 5-inch Installation Speaker Cabinet

The Bosch LB20 series is the latest member of the Bosch family of Commercial Loudspeakers for indoor and outdoor applications. Acoustically matched and aesthetically compatible with other Bosch models, the LB20 series incorporates innovative features that efficiently and effectively address the real-world needs of both the installer and the end-user - easy installation and exceptional Bosch audio performance in an incredibly versatile format.

Indoor and Outdoor Applications

The LB20 series of Premium commercial loudspeakers for indoor and outdoor applications offers easy installation and exceptional Bosch audio performance in an incredibly versatile format.

Compact and Cost-Effective

The LB20 series was designed from the ground up to be the new go-to choice for distributed sound systems – compact and cost-effective with no compromises. All models offer Bosch-engineered components for superior sound quality, low-profile looks and robust reliability for a wide range of indoor and outdoor applications.

New Wall-Mount System

The innovative, new wall-mount system makes installation literally "as easy as 1-2-3" - quicker and easier than ever before. Attach the wall-mount (a built-in bubble level saves time) and terminate the cables inside, then apply the paint cover to protect the wall-mount. Finally, simply slide the pre-wired speaker with an adjustable arm onto the wall-mount and lock it into place.

Weatherproof

The LB20-PC60EW-5 has been carefully engineered to resist the toughest weather conditions, without compromising on performance for indoor applications. The full-range speaker is IP65 rated, and its weatherproofing is complemented with exceptional cabinet and grille resistance against sun, salt, moisture, and chlorine.

Features

  • Carefully engineered for the toughest weather conditions (IP65)
  • Long-throw 5.25" (133 mm) woofer housed in a UL 94-5VB fire-rated ABS plastic for extended LF performance down to 55 Hz
  • 75W power handling provides for 108 dB maximum SPL (114 dB Peak)
  • 60W transformer with 8 Ω pass-through
  • EN 54-24

Specifications

Frequency Response (-3 dB) 90 Hz - 20 kHz
Frequency Response (-10 dB) 55 Hz - 20 kHz
Sensitivity 89 dB
Max SPL (Calculated) 108 dB, 114 dB Peak
Coverage Angle Horizontal 90°, Vertical 90°
Power Handling 75W (300W Peak) Continuous Pink Noise (100 hours)
Low Z Yes
Nominal Impedance 8Ω
Minimum Impedance 6.5 Ω
Recommended High-Pass 60 Hz (24 dB/octave)
Input Transformer (70V/100V) 60W
Transformer Taps 70V: 60W, 30W, 15W, 7.5W, 8Ω
100V: 60W, 30W, 15W, 8Ω
LF Transducer 5.25" (133 mm)
HF Transducer 0.75" (20 mm)
Connectors Removable locking 4-pin connector (Euroblock) - (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm)
Environmental IP-65 (per IEC-60529)
Color White (RAL 9003)
Dimensions (H x W x D) 10" (255 mm) x 7.1" (180 mm) x 5.9" (150 mm)
Net Weight 7.1 lbs (3.2 kg)
Shipping Weight 21 lbs (9.5 kg)

DOCUMENTS

In The Box

  • 2 Speakers
  • 1 Allen wrench
  • 4 Safety screws for the U-Brackets
  • 2 U-brackets
  • 2 Weather covers
  • 8 Weather cover screws
  • 2 Grille logos (spares)
  • 1 Installation manual
