CHAUVET DJ Hurricane Haze 1D Water-Based Haze Machine (Discontinued)

Description

The Hurricane Haze 1D creates a light water-based haze to enhance any light show. Easily set the DMX address and standalone operation using the digital display. The haze output and blower speed can be adjusted in stand-alone mode using the digital display with no controller required. Output can also be adjusted using the included FC-T wired timer remote and DMX. A built-in sensor helps prolong the hazer’s life by stopping the pump automatically when the fluid level is low.

Features

• Water-based Haze machine creates a light haze to enhance any light show
• Adjust the haze output and blower speed in stand-alone mode using the digital display (no controller needed)
• Easily set the DMX address and stand-alone operation using the digital display
• Low fluid sensor stops the pump and prolongs its life
• Adjustable output when using the included FC-T wired timer remote and DMX
• Three indicator LEDs show the status of the fill tank, as follows:
• Red - the fluid tank is currently heating up
• Blue - the fluid tank is ready
• Flashing Blue - the fluid tank requires refilling

Specifications

DMX Channels	1
DMX Connectors	3-pin XLR
Heat-Up Time	1 min
Input Voltage	120 VAC, 60 Hz
Power and Current	840W, 6.8 A @ 120 V, 60 Hz
Approvals	CE
Tank Capacity	0.4 gal (1.5 l)
Output	700 cfm
Fluid Consumption	10 ml/min
Optional Controllers	FC-W, FC-M
Compatible Fluids	HFG
Dimensions	12.5" (318 mm) x 10.5" (268 mm) x 9.8" (250 mm)
Weight	8.4 lbs (3.7 kg)

DOCUMENTS

In The Box

• (1) Hurricane Haze 1D
• (1) Wired Remote
• (1) Power Cord
• Warranty Card
• Quick Reference Guide
