The Chief SYSAUW suspended ceiling projector system cuts installation time by one-third and includes everything needed to complete the majority of installations.

Projector not included.

Description

Chief SYSAUW Suspended Ceiling Projector Mount

Designed for speed and flexibility from an ordering and installation standpoint. Chief's SYSAU suspended ceiling projector system cuts installation time by one-third and includes everything needed to complete the majority of installations.

Features
  • System comes out of box in the order needed with mount and column preassembled
  • Adjustable ceiling plate allows placement above or below tile and accommodates inconsistent T-grids
    • Compatible with 2' x 2', 2' x 4', 60 x 60cm, & 62.5 x 62.5cm ceiling grids
  • Detachable electric plate for pre-wiring
    • Compatible with popular 2 gang adjustable mud rings
  • Tool-FreeMicrozone adjustment eliminates the need for set screws
  • CentrisTechnology enables effortless fingertip positioning with new tool-free lockdown
  • Adjustable 0-12" column with dual inlay channels for high and low voltage cables
  • Q-Lock Quick Release Lever provides quick connect/disconnect of the projector for service and enhanced security with an integrated key and lock system
  • Improved universal interface for easier lock/unlock at projector connection

Specifications
Adjustments Roll, Pitch, Yaw (3°, 10°, 360°)
Certifications UL Listed
Color White
Extension 0 - 12" ( 0 - 304.8 mm)
Solution Type Universal
Weight Capacity 35 lbs (15.9 kg)
Overall Dimensions (H x W x D) 19.82" (503.5 mm) x 7.25" (184.2 mm) x 24.94" (633.6 mm)
Shipping Weight 19.6 lbs (8.89 kg)
