Cloud Electronics 46-240 4 Zone 4 x 240W Integrated Mixer Amplifier

Cloud Electronics 46-240 4-Zone Integrated Mixer Amplifier

The Cloud 46-240 is a powerful and versatile 4-zone mixer amplifier designed for a range of commercial audio applications, including pubs, restaurants, leisure centers, offices, and retail spaces. This rack-mountable 2U unit delivers 240 watts per zone with support for both low-impedance (4/8 ohms) and high-impedance (70V/100V) speaker configurations. Its efficient Class-D amplifiers are protected with built-in limiters, thermal safeguards, and short-circuit protection, ensuring reliable performance even under demanding conditions.

This model features six stereo line inputs (four of which are balanced), two microphone inputs with priority options, and two facility inputs for flexible audio routing. The system also includes remote music level and source selection capabilities, making it user-friendly for staff and operators. Additional utility outputs with microphone and music gain controls enhance its adaptability to complex setups.

For integration into larger systems, the 46-240 supports Ethernet and RS232 connections and includes a digital paging interface compatible with Cloud PM paging microphones. A fire alarm interface with remote music mute ensures compliance with safety protocols. Its auto-standby function reduces power consumption when not in use, contributing to energy efficiency.

The unit offers fine-tuned audio control with high and low EQ adjustments for line and mic inputs and boasts a broad frequency response from 20 Hz to 20 kHz. The robust, universal power supply and compact design make it a reliable and space-saving choice for multi-zone audio distribution in various environments​

• 4-zone mixer amplifier with 240W output per zone
• Supports 4Ω/8Ω, 70V, and 100V speaker configurations
• 6 stereo line inputs (4 balanced) and 2 microphone inputs with priority options
• Class-D amplification with built-in limiters and thermal/short-circuit protection
• Remote music level and source selection capability
• Utility output with independent mic and music gain controls
• Ethernet and RS232 connectivity for system integration
• Digital paging interface for Cloud PM microphones
• Fire alarm interface with remote music mute functionality
• Auto-standby mode for energy efficiency
• High and low EQ adjustments for precise audio control
• Compact 2U rack-mount design with universal power supply

Spec Sheet
