Community W2-2W8T Dual 2 Way Weather Resistant Loudspeaker
Part # W2-2W8T
Model # W2-2W8T

The Community W2-2W8T employs an innovative 2 way loudspeaker design with a factory-installed 200W autoformer for 70V/100V lines with selectable taps at 200, 100, 50 and 25W.

Availability: Usually arrives in 12-16 business days

* Required Fields

Pro Acoustics Price $2,600.00

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

Exhibiting a true 120º wide coverage pattern, the WET2W8T employs an innovative two-way loudspeaker design. The WET2W8T satisfies a variety of sound reinforcement, down-fill, underbalcony stage edge fill, monitoring, and similar uses.

The W2-2W8T includes a factory-installed 200-watt autoformer for 70V/100V lines with selectable taps at 200, 100, 50 and 25 watts.

The LF drivers and centrally placed ultra-wide 120º HF pattern control horn have been engineered to provide superior uniform pattern over the widest possible bandwidth. The unique molded "Super-V" configuration of the LF drivers provides exceptional uniform mid-range coverage that would be impossible to create with a conventional flat wood baffle plate. Precise modeling and documentation prove that woofer/ horn/woofer placement in traditional underbalcony fill-type loudspeaker designs exacerbates severe vertical lobing. The Super-V configuration prevents the collapse of the horizontal coverage pattern throughout its range, especially the critical voicerange, when oriented in its usual horizontal position.

Engineered for permanent installations, the loudspeaker enclosure and faceplate are constructed of multilayer glass composite, resulting in extreme structural strength. A threelayer Weather-Stop™ grille of stainless steel mesh and open cell foam provides weather-resistance to the internal components, while all exposed hardware is stainless steel or powder-coated aluminum extrusion. A stainless steel mounting yoke is included.

Features

Features

  • All-Weather, Multilayer Glass Composite Enclosure
  • Weather Inert Driver Diaphragms
  • Stainless Steel Hardware
  • Integral Mounting Points
  • High Power Passive Crossover
  • Ferrofluid-Cooling
  • Available in Black or White Finishes
  • Weather-Resistant Stainless Steel Grille
  • Stainless Steel Mounting Yoke Included
  • Available with or without a 200W Autoformer for 70V / 100V Applications
Specification
FormatTwo-way, full-range
Operating Range65 Hz - 18 kHz
Frequency Response80 Hz - 15 kHz (±3 dB)
Dispersion (-6 dB)120º H x 60º V
Maximum SPL @1m121 dB continuous / 128 dB peak
Crossover Frequency1 kHz
Sensitivity in SPL (1W/1m, Free Space)97 dB (100 Hz - 13 kHz, 1/3 octave) 98 dB (250 Hz - 4 kHz, speech range)
Max Power Handling (Passive Mode)250W RMS, 600W Program
Transformer Taps200W, 100W, 50W and 25W
Impedance (Passive)Nominal 8Ω / Min. 4.6Ω at 190Hz
Low Frequency Transducers2 x 8" (203 mm)
High Frequency Transducers1" (25.4 mm)
EnclosureHand-laminated fiberglass
FinishBlack or white gelcoat
Rigging ProvisionsTwo 1/2-13 rigging points; yoke bracket included
Input Connection16-2 SJOW (12 ft / 4m)
GrilleThree-layer Weather-Stop™
Dimensions (H x W x D)10.13" (257 mm) x 20" (508 mm) x 11.5" (292 mm)
Net Weight40.4 lbs (18.3 kg)
Shipping Weight48 lbs (21.8 kg)
