Conference Room Sound System with 4 JBL In-Ceiling Loudspeakers and CSMA Mixer Amplifier

Part #:
CFSS-48128CSMA180
Model #:
CFSS-48128CSMA180
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL
This JBL Conference Room Sound System is the ideal room set up for conference rooms, trainings, meetings, and presentations and ensures that speakers and presenters are easily heard.

Description

This JBL Conference Room Sound System is the ideal room set up for conference rooms, trainings, meetings, and presentations and ensures that speakers and presenters are easily heard.

The JBL 8128 is a 8-inch, full-range, cost-effective loudspeaker for commercial applications. The 8128 features high-fidelity performance in an easy to install package. The system’s high sensitivity drivers deliver maximum sound levels using minimal amplifier power. With its contemporary grill design, 70V/100V taps and an open-back design, the 8100 series brings elegance and performance to basic commercial sound systems, or any application not requiring a back can for installation.

The JBL CSMA series of Mixer-Amplifiers are a professional tool designed and built for Installed sound applications. The CSMA 180 is a, 80 W, single channel model with four mixer channels. It provides mixer capability with independent level control for each input channel and amplification with a choice of low impedance, 70 V or 100 V outputs. The product includes a rack mounting kit for installations to a cabinet. The system can be easily expanded with additional JBL Commercial Series Amplifiers and Commercial Series Mixers.

Features

JBL 8128 In-Ceiling Loudspeaker:

  • Clear, High-Fidelity Performance
  • Dog-ears for easy Blind Mount Installations
  • High Sensitivity (97 dB, 1W, 1m) for Maximum Power Efficiency
  • 6W Transformer for use of 70V / 100V Distributed Lines

JBL CSMA 180 Mixer Amplifier:

  • Energy Star certified
  • Fanless, space-saving 1U design
  • Illuminated rings make them easy to see and operate
  • Euro-block type mic/line input and output connectors
  • Independent bass and treble controls for each output channel
  • Supports 70 V and 100 V distributed audio systems without needing a separate transformer
  • Remote volume control capability using JBL CSR-V module and standard Ethernet cable
  • Phantom power, priority muting, and configurable output routing
  • Universal power supply accepts AC voltages from 100 to 240 VAC, 50/60 Hz
  • Three-year, no-fault fully transferable warranty



System Includes

  • (4) JBL 8128 In-Ceiling Loudspeaker
  • (1) JBL CSMA 180 Mixer Amplifier
