Crown MA 12000i 2 Channel Power Amplifier

Home /
Crown MA 12000i 2-Channel Power Amplifier (Discontinued)

Description

Details

The Macro-Tech i Series includes onboard analog signal processing and a built-in network connection.

Modern power amplifiers are sophisticated pieces of engineering capable of producing extremely high power levels. They must be treated with respect and correctly installed if they are to provide the many years of reliable service for which they were designed.

In addition, MA-i Series amplifiers include a number of features which require some explanation before they can be used to their maximum advantage.

Features

Features

The Crown Macro-Tech i Series continues the Macro-Tech legacy of unparalleled sonic accuracy and detail, putting sound quality above all else
Patented, cutting-edge Class-I circuitry gets more power out of an amplifier with less waste
Rugged construction ensures that all Macro-Techs are built to withstand years of abuse on the road
Global Power Supply — designed to deliver maximum power no matter what country you work in
Built-in load, line voltage, input and output monitoring
Standard Ethernet networking via System Architect® lets system operators monitor and control the amplifier from any location
High power density, up to 9000 watts in a 2U chassis
Highest output voltage in the industry (200V peak) provides clean transient peaks
Precision detented push-to-mute attenuators with multiple LEDs that show attenuator position, mute status or level
Light weight due to aluminum chassis, special internal construction and switching power supply
Thermal management controller and two discrete thermal zones with variable-speed fans, forced-air cooling
Advanced protection circuitry guards against: shorted outputs, DC, mismatched loads, general overheating, under/over voltage, high-frequency overloads and internal faults

Specification

Frequency Response	± 0.25 dB
Signal to Noise Ratio	> 108 dB
Total Harmonic Distortion (THD)	< 0.1%
Total Harmonic Distortion (THD)	< 0.35%, 20 Hz to 20 kHz
Intermodulation Distortion (IMD)	< 0.35%
Damping Factor (20 Hz to 100 Hz at 8 ohms)	> 5000
Crosstalk (below rated power, 20 Hz to 1 kHz)	> 80 dB
Common Mode Rejection (CMR) (20 Hz to 1 kHz)	> 55 dB, typically > 70 dB
DC Output Offset (Shorted input)	< ± 3 mV
Input Impedance (nominal)	10 kilohms balanced, 5 kilohms unbalanced
Maximum Input Level	+20 dBu typical
Load Impedance	Stereo: 1/2/4/8/16 ohms Bridge Mono: 2/4/8 ohms
Input Sensitivity	1.4V, 32 dB gain, and 26 dB gain
Voltage Gain	39.3 dB to 24.5 dB
Required AC Mains	Universal AC input, 100-240VAC , 50/60 Hz (±15%). Maximum AC mains voltage 264VAC
Cooling	Dual-zone, microprocessor controlled, continuously variable speed fans, front-to-back airflow
Front Panel	Cast aluminum with integrated handles
Protection	Amplifier is protected against reactive loads, faults and shorts
Dimensions (H x W x D)	3.5" (88.9 mm) x 19" (482.6 mm) x 16.2" (411.5 mm)
Weight	28 lbs (12.7 kg)
Shipping Weight	36 lbs (16.3 kg
