- Description
Details
No Computer Needed
Yes! Take command of the DJ booth with the all-new standalone MCX8000 and transform an ordinary set into a full concert experience. Two hi-definition display screens control Denon DJ’s revolutionary standalone Engine 1.5 software and Serato® DJ operation. It’s fully loaded with a 4-channel digital mixer that comes with 3 built-in instant effects for Engine software and line inputs. The solid metal construction is buttoned-up with velocity-sensitive performance pads for cues, rolls, slicer, and samples.Built-in Engine Software
What is Engine? Engine is the exclusive revolutionary DJ software under the hood of the MCX8000 that enables you to perform without a laptop. This amazing software brings you front and center to play your sets with the ability to just use a thumb drive with Engine. Engine 1.5 software has many advantages once installed on your PC/Mac to create your playlists/crates set cue points and analyze your entire library.
Serato DJ Ready
You have the advantage of having the best of both worlds since the MCX8000 is compatible with the latest Serato DJ software and enables you to use 4-channels. There is also a DVS upgrade package, giving the MCX8000 unlimited possibilities.
Hand-Off With Ease
Transition between two DJs with ease! There are no interruptions between sets as Engine software enables the DJ to either plug into the MCX8000 via USB or Serato DJ while in sync with the vibe. There are two USB ports for flash drives and around the back of the MCX8000, there is a powered USB port for external hard drive used with Serato DJ.
Sound and Effects Matters
Built with onboard sound effects and a 24-bit pristine sound, the MCX8000 delivers a high-quality controller with XLR outputs for both the DJ booth and PA system. To top off the amazing sound, there are three sound effects built in: delay, echo, and noise.
Next Generation In High-Performance Media Player/Controller
The MCX8000 is the only media player/ controller that has its own built-in software and interfaces seamlessly with Serato DJ. We propel the DJ into the next generation of high-performance standalone technology (Engine) with high-definition screens, simultaneously run Serato DJ, and a solid professional grade 24-bit 4-channel mixer which makes you limitless.- Features
Features
- Includes revolutionary Denon DJ Engine standalone technology
- 2 USB inputs for Engine playback in standalone mode
- Includes 4-deck Serato DJ software
- 2 high-definition displays show Engine and Serato DJ operation
- Professional 4-channel digital mixer with 2 microphone inputs
- 3 built-in instant effects for Engine playback and line inputs
- Velocity-sensitive performance pads for cues, rolls, slicer and samples
- Stage LinQ network connection to control lighting and video
- Serato DVS Upgrade Ready
- Metal construction
- Specification
Playable Media Type USB mass-storage devices (flash memory, external HDD enclosures) connected to toppanel USB Ports 1/2 File Systems FAT16
FAT32File Formats AAC (CBR/VBR, 44.1 kHz, stereo 64–320 kbps)
AIF/AIFF (44.1 kHz, 16-/24-bit stereo)
MP3 (CBR/VBR, 44.1 kHz, stereo 32–320 kbps)
WAV (44.1 kHz, 16-/24-bit stereo)Storage Capacity 2 TB maximum per USB port Engine Database Size < 100,000 playable files
< 512 crates with 7 subcrate layers
< 512 playlistsChannels Channels 1 & 2 PC (Serato DJ), Engine, or Line Channels 3 & 4 PC (Serato DJ), Line, or Phono (DVS) USB Audio/MIDI Interface Sampling Rate: 44.1 kHz
Bit Depth: 24-bitFrequency Response 20 Hz – 20 kHz (+1 dB) Dynamic Range > 108 dB (A-weighted) Signal-to-Noise Ratio > 88 dB (A-weighted) Headroom Line Input: > 18 dB
Mic Input: > 20 dB
Outputs: > 20 dBMic Input EIN: < -119 dBu (Rs = 150 Ω, DIN)
CMRR: > 80 dB (1 kHz, unity)Channel Separation < -110 dB (1 kHz, unity) THD Line/Phono < 0.01%
Mic < 0.05%Analog Input Mic Inputs: -40 dBu (unity); -60 dBu (minimum)
Line Inputs: +18 dBV (maximum); 0 dBV (unity)Analog Output Master Outputs (balanced): +24 dBu (maximum); +4 dBu (unity)
Master Outputs (unbalanced): +20 dBu (maximum); 0 dBu (unity)
Booth Outputs (balanced): +24 dBu (maximum); +4 dBu (unity)
Headphones Outputs: > 150 mW @ 40 ΩConnections Audio Outputs 2 XLR outputs (master left/right, balanced)
1 RCA output pair (master left/right, unbalanced)
2 XLR outputs (booth left/right, balanced)
1 1/4” (6.35 mm) stereo output (headphones)
1 1/8” (3.5 mm) stereo output (headphones)Audio Inputs 2 RCA input pairs (line-level, unbalanced)
2 RCA input pairs (phono- or line-level, unbalanced)
1 XLR+1/4” (6.35 mm) input (Microphone 1)
1 1/4” (6.35 mm) input (Microphone 2)Other 2 USB ports (for USB drives, 5 V, 1 A)
1 USB port (to computer)
1 USB hub port (to computer, 5 V, 500 mA)
1 Ethernet port
1 power adapter inputPower Power Adapter 12 V DC, 5 A, center-positive Input Voltage 100–240 VDC, 50/60 Hz Consumption Maximum: 26.6 W @ 264 V / 50 Hz, 253 mA Dimensions (H x W x D) 2.8" (71 mm) x 28.7" (728 mm) x 17" (432 mm) Weight 18.4 lbs (8.34 kg) Shipping Weight 23.61 lbs (10.71 kg) - Documents
Documents
- In The Box
In The Box
- (1) MCX8000 DJ Controller
- (1) Power Adapter
- (1) USB Cable
- Quickstart Guide
- Software Download Card
- Safety & Warranty Manual
