DVDO AudioE-1 4K HDMI 2.0b Audio Extractor
DVDO AudioE-1 4K HDMI 2.0b Audio Extractor
By DVDO

DVDO AudioE-1 4K HDMI 2.0b Audio Extractor

Write a Review
Part #:
DVDO-AudioE-1
Model #:
DVDO AudioE-1
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112
Email

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM 1-888-256-4112
Email Contact us by email or
our simple form. SEND EMAIL
The DVDO AudioE-1 HDMI 2.0b audio extractor extracts audio from HDMI sources to optical SPDIF or L/R analog outputs while passing through 4K@60 Hz video, HDR, high-bit-rate audio, Dolby Atmos, DTS-HD, and CEC for home theater and professional applications.

Description

DVDO AudioE-1 HDMI 2.0b Audio Extractor

The AudioE-1 HDMI 2.0b audio extractor allows seamless extraction of audio from HDMI sources while maintaining pristine 4K video quality. Supporting resolutions up to 4K@60 Hz with YUV 4:4:4 chroma and HDCP 2.2, it delivers uncompromised video and high-dynamic-range (HDR) pass-through for modern home theater and professional setups.

The extractor outputs audio to digital optical SPDIF or analog stereo L/R while passing through the original HDMI audio to HDMI and optical outputs. It supports high-resolution formats including LPCM 2CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos, and DTS-HD Master Audio. For analog stereo, the device provides a bitstream down-mix while maintaining clarity and fidelity.

Designed for versatile applications, the DVDO-AudioE-1 supports high-bit-rate (HBR) audio, 10-bit HDR, CEC pass-through, and audio sampling rates up to 192 kHz. It is ideal for residential audio, home theaters, hospitality environments, conference rooms, digital signage, educational facilities, and houses of worship. Easy installation and plug-and-play operation make it ready for professional and consumer use.

Features
  • HDMI 2.0b (18 Gbps), HDCP 2.2, and DVI compliant
  • Supports video resolutions up to 4K@50/60 Hz (YUV 4:4:4)
  • Extracts HDMI audio to optical SPDIF or L/R analog stereo
  • HDMI audio pass-through to HDMI and optical outputs
  • Bitstream audio down-mix to L/R analog output
  • Supports LPCM 2CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos, DTS-HD Master Audio
  • High Bit Rate (HBR) audio pass-through up to 192 kHz
  • 10-bit HDR (High Dynamic Range) and CEC pass-through
  • Ideal for home theater, residential audio, hospitality, conference rooms, education, and digital signage

Specifications
Compliance HDMI 2.0b/HDCP 2.2 & 1.4
Inputs 1 x HDMI Type A [19-pin female]
Outputs 1 x HDMI Type A [19-pin female]
1 x L/R Audio [RCA]
1 x Optical [S/PDIF]
Video Resolutions Up to 4K2K@50/60 Hz (YUV4:4:4), 4K2K@30 Hz, 1080p@120 Hz, 1080p 3D@60 Hz
Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 10-bit, 12-bit
Maximum Data Rate 18 Gbps
Audio Formats HDMI (audio pass through): LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+,
Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
L/R Audio: Analog Stereo 2CH
Optical Audio: LPCM 2CH, Dolby Digital 2/5.1 CH, DTS 2/5.1CH
Enclosure Black metal
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 20% to 90%, non-condensing
ESD Protection Human body model - ±8 kV (air-gap discharge) & ±4 kV (contact discharge)
Power Supply Input: AC 100-240V 50/60 Hz/Output: DC 5V/1A (US/EU standards, CE/FCC/UL certified)
Power Consumption 1.25W (Max)
Dimensions (H x W x D) 0.8" (20 mm) x 2.9" (73.5 mm) x 2.4" (60.7 mm)
Weight 0.3 lbs (0.14 kg)

DOCUMENTS

In The Box
  • (1) HDMI 18 Gbps Audio Extractor
  • (1) 5V/1A Power Adapter
  • (1) User Manual
