The HUBINBM HUB interface links the Eartec HUB mini transceiver base station to an existing Blackmagic wired intercom system, allowing up to eight wireless headsets to communicate with the wired partyline in full duplex. The interface is designed for Blackmagic 4-wire intercom systems and provides hands-free communication for wireless users as if they were connected to the wired system by cable.
When the HUB, available separately, is linked, the system provides two channels of communication, allowing separate headsets on channels A and B or the entire team to be linked with the push of a button. The HUBINBM operates using DECT (Digital Enhanced Cordless Telecommunications) technology in a non-licensed band and provides a range of up to 900' in all directions.
| Compatibility | Blackmagic Wired Intercom Systems |
|---|---|
| Wireless Users | Up to 8 |
| Communication | Full Duplex |
| Number of Channels | 2 Channels |
| Channel Configuration | Channels A and B; Link Entire Team |
| Wireless Range | Up to 900 ft in all directions |
| Wireless Technology | DECT (Digital Enhanced Cordless Telecommunications) |
| Interface Type | Wired to Wireless |
| FCC Licensing | Not Required |
| Dimensions (H x W x D) | 6" (152.4 mm) x 3" (76.2 mm) x 1" (25.4 mm) |
| Weight | 1 lb (0.45 kg) |
