EAW UX48 Greybox Enabled Networked Digital Signal Processor (Discontinued)

The UX48 represents EAW's next-generation Greybox^TM-enabled networked digital signal processor. The UX48 offers Dante, analog and AES inputs and outputs combined with the power of EAW's Focusing^TM and DynO^TM processing, maximizing performance in any system. The front panel offers access to quick setup functions, with advanced control via EAW Resolution^TM, integrating prediction, control and monitoring in one platform.

• EAW minimal signal path design
• 48kHz sampling frequency provides for a nominally flat response beyond 40kHz
• Three rotary encoders, illuminated buttons and graphical display provide a rapid, intuitive and user-friendly control interface
• High speed capable and flexible Ethernet communications that supports DHCP, static-IP and auto-IP and direct connection to a computer without the need for a router or a switch
• Class leading sonic performance achieved by the use of state of the art converters, a 4th Generation Analogue Devices Sharc DSP and highly advanced DSP algorithms
• Powerful Drive Module concept, abstraction from device centric to speaker based control
• Innovative Component Presets to allow individual outputs to be used for selected drivers of a loudspeaker system
• Twelve layers of Parameter Overlays for trouble-free Grouping
• Unique VX limiter providing dynamic control for passive 2-way enclosures
• Unique LIR linear phase crossover shapes giving FIR-like performance without the drawbacks
• Linear phase HF system EQ profiling which provides perfect integration between enclosures
• Innovative excursion control limiter with sliding High Pass Filter; limits only the damaging low frequencies
• Transducer thermal modeling provides regulation limiters, addressing long term overload
• Overshoot limiter governs amplitude of transient signals retaining average power whilst constraining peak energy
• Dante audio networking with automatic fall over to Analogue or AES3
• AES3 inputs and outputs, switchable in pairs
• High performance 'universal mains' switch mode power supply, designed in-house
• Greybox^TM enabled
