Ecler HZA4-120F 4-Channel High-Impedance Flexi-Power Amplifier

Ecler HZA4-120F 4-Channel Flexi-Power Amplifier

The HZA4-120F is a four MERGING channel amplifier with direct 4 x 120 WRMS @ 100V line (high impedance) outputs. It integrates ECLER's proprietary SPM 100 Technology - Channel N, which allows for 100V speaker lines connection without using 100V line transformers at the amplified outputs, as this kind of amplifiers usually do. This fact has many advantages, being the main ones the audio quality improvement (especially in the low-end frequencies) and the convection cooling, 100% silent.

• 4 mono balanced inputs
• 4 x 120W amplified outputs (100V line level)
• 4 volume remote control ports (0 - 10 VDC)
• Euroblock connectors
• SPM 100 amplification Technology - Channel N (no 100V output transformers used):
• Improved frequency response (especially at the low-end)
• Convection cooling (100% silent and increased reliability)
• Great efficiency
• Low weight
• Auto stand-by function after 2 minutes without audio input signals, with instantaneous auto-recovery
• Thermal protection
• Overload protection
• Anti-clip system
• Volume control knobs on front panel with protection cap, against undesired manipulation
• Every 2, 3 or 4 adjacent channels can be merged, adding their output power and managing their signal routing and volume control as a single merged channel

Spec Sheet

Manual
