Clear, powerful, and musical, the Live X series was born to command the stage for professional music performance. Available in both powered and passive versions, Live X loudspeakers offer top-quality components in remarkably affordable configurations that put the EV-quality experience within reach for artists, engineers, and live-sound businesses. Designed for a wide range of portable sound applications, Live X loudspeakers are housed in hardy stackable enclosures of solid wood, making them lighter than comparable-quality composite or plastic boxes and therefore easier to load, transport, and set up. With high output, extended frequency range, and high sensitivity, Live X loudspeakers are clean, flat, and hot, making music of all kinds sound its best. The Live X series is serious gear for serious sound.
| Axial Sensitivity | 95 dB |
|---|---|
| Case Material | 9-ply, 15 mm Plywood, Internally Braced, with Texured Paint |
| Woofer Size | 15" (381 mm) |
| Frequency Response (-3 dB) | 75 - 18 kHz |
| Frequency Response (-10 dB) | 50 - 20 kHz |
| Recommended High-Pass Frequency | 40 Hz |
| Max. SPL/1m (calc) | 134 dB Half Space |
| Coverage (H x V) | 90° x 50° |
| Power Handling | 400W Continuous, 1600W Peak |
| LF Transducer | (1) EVS-15K, 15” (381 mm) Woofer |
| HF Transducer | DH-1K, 1.5” (39 mm) Titanium Diaphragm Compression Driver |
| Crossover Frequency | 1.7 kHz |
| Nominal Impedance (Passive) | 8Ω |
| Minimum Impedance | 7.4Ω |
| Connector Type | Parallel Neutrik NL4 |
| Grill | 18GA Steel with Black Powdercoat |
| Dimensions (H x W x D) | 27.89" (708 mm) x 17.02" (432 mm) x 15.05" (382 mm) |
| Net Weight | 48.2 lbs (21.9 kg) |
| Shipping Weight | 58.6 lbs (26.6 kg) |
Usually arrives in 5-9 business days.
