Electro-Voice EVF-1152D-FG Premium 15" 2-Way Weatherproof Loudspeaker

By Electro-Voice

Electro-Voice EVF-1152D-FG Premium 15" 2-Way Weatherproof Loudspeaker

Name: Electro-Voice EVF-1152D-FG Premium 15" 2-Way Weatherproof Loudspeaker
Brand: Electro-Voice
SKU: BOSCH-EV-EVF-1152D-FG
Price: 5259 USD
Availability: InStock

Write a Review

Part #:

F.01U.272.949

Model #:

EVF-1152D-FG

Current Stock:

Availability: Usually arrives in 10-15 business days

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Electro-Voice® EVF-1152D-FG Weatherproof 600W (Passive) loudspeaker offers a 2-way front-load design featuring the DVX3151A with forced air cooling, Electro-Voice’s latest 15" woofer innovation, accompanied by the DH7N high-frequency compression driver mounted on a new, fully rotatable 12" x 12" waveguide.

Description

The Electro-Voice® EVF-1152D 600 watt (Passive) loudspeaker offers a two-way front-load design featuring the DVX3151A with forced air cooling, Electro-Voice's latest 15" woofer innovation, accompanied by the DH7N high-frequency compression driver mounted on a new, fully rotatable 12" x 12" waveguide (available in 40° x 30°, 60° x 40°, 60° x 60°, 90° x 40°, 90° x 60°, and 90° x 90° patterns). System is capable of passive or bi-amp operation. Available in black or white, with a choice of three finishes: EVCoat™ (interior use), PI (indirect weather exposure), and FG (fiberglass, for direct weather exposure).

EVF "D" high definition systems are equipped with our highest performance DVX series symmetric drive woofers and the DH7N 3" pure titanium compression driver. The result is lower distortion, cleaner sound reproduction at a given output level, compared with the equivalent "S" version.

Features

Compact and lightweight
Low distortion, high efficiency
Ideal for fixed installations
DVX3151A woofer with fully symmetric drive
3" DH7N titanium/neodymium HF compression driver
Rotatable Constant Directivity waveguide
Six available patterns with coverage from 40º to 90º
100 dB sensitivity, 134 dB maximum SPL
Power handling: 600W continuous, 2400W peak
Fourth-order crossover with HF protection
Trapezoidal 13-ply birch enclosure in three finishes: EVCoat, PI and FG
22 M10 threaded suspension points
Transformer kit available for distributed systems
Four M10 metric eyebolts included

Specifications

Frequency Response (-3 dB)	70 Hz – 18 kHz
Frequency Range (-10 dB)	40 Hz – 21 kHz
Recommended High-Pass Frequency	45 Hz
Sensitivity (SPL, 1 W/1 m)	100 dB
Max. SPL @ 1 m (calc.)	134 dB
System Power Handling (Continuous, Program, Peak)	600W, 1200W, 2400W
Nominal Impedance (Passive)	8Ω
Minimum Impedance	6Ω
Input Connections	Phoenix/Euroblock style screw terminals; dual-gland-nut input-panel cover
LF Transducer	15" DVX3151A woofer
HF Transducer	3" DH7N diaphragm compression driver
Internal Passive Crossover Frequency	1300 Hz
Enclosure Material	13-ply weather-resistant birch
Grille	18 ga Stainless, Powdercoat with hydrophobic cloth behind
Environmental	IEC 60529 IP55
Suspension	(22) M10 Threaded Points (one EBK-M10-EVI kit of four forged eyebolts included)
Dimensions (H x W x D)	30.26" (768.6 mm) x 18.5" (469.8 mm) x 18.37" (466.6 mm)
Net Weight	75.7 lbs (34.4 kg)
