Electro-Voice EVID 12.1 12 inch Surface Mount Subwoofer (Discontinued)

Part #:
EVID 12.1
Model #:
EVID 12.1
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Electro-Voice EVID 12.1 is ideal for supplementing the bass response of any EVIDTM model in an indoor application. It is particularly useful in sports bars, dance floors, retail environments, health clubs, restaraunts, etc.

Description

The 12.1 is ideal for supplementing the bass response of any EVIDTM model in an indoor application. It is particularly useful in sports bars, dance floors, retail environments, health clubs, restaraunts, etc. The 12.1 adds the extra dimension of a powerful low end where foreground music is desired.

The 12.1's slot-loaded design allows for flexible mounting and placement while delivering the smoothest bass response possible. The 12-inch high-excursion woofer, with its dual voicecoil design, enables both the L/R channels to feed into the speaker while at the same time providing crossed-over outputs for up to 4 satellite speakers. If desired, the 12.1 can be powered separately for an even more powerful presence. The 12.1 features reinforced steel-fastener construction that allows for a variety of mounting configurations.

Features

  • 12-inch High-Excursion LF Transducer
  • Supplemental bass for indoor systems
  • Ideal for sports bars, dance floors, retail and health clubs
  • High-excursion woofer with dual voice coil to accommodate L/R channels
  • High sensitivity, high power-handling
  • Crossed-over pass-thru for up to four satellite speakers
  • Trapezoidal shape for flexible placement
  • Steel-reinforced cabinet with mounting hardware included

Specifications

Frequency Response (-10 dB) 40 Hz - 180 Hz
Power Handling 175W Cont. Program Per Coil
Sensitivity 1 W/1 m 106 dB
Impedance
Max. Calculated SPL 125 dB
LF Transducer 12" (300 mm) High-Excursion Dua Voice-Coil
Terminals Spring -Loaded
Enclosure Material MDF, Steel Fastener Reinforced
Included Accessories Mounting Bracket and Hardware
Dimensions (H x W x D) 16.25" (412 mm) x 23" (584 mm) x 12" (305 mm)
Net Weight 40 lbs (18.1 kg)
Shipping Weight 48 lbs (20 kg)
