The Electro-Voice TG7 Power Amplifier has a microprocessor controlled operation management system that provides useful features such as compound thermal management (preventing the unit from switching off in excessive thermal environment), automatic mains voltage detection and a circuit breaker control that allows the TG-7 to operate on a 30A (120V) respect. or 16A (230V) circuit breaker with normal music signal.
The TG7 uses a grounded bridge 3-step class-H topology to ensure the highest acoustic performance and reliability. The TG Series also offers the power and transient response to drive subwoofers and along with the low distortion for critical HF signals. The high capacity switch-mode power supply provides the headroom needed to ensure high dynamic outputs and reliable operation on extreme low loads.
| Continuous rated power (1k Hz, THD 1%) 2Ω | 3500 Watts |
|---|---|
| Continuous rated power (1k Hz, THD 1%) 4Ω | 2500 Watts |
| Continuous rated power (1k Hz, THD 1%) 8Ω | 1500 Watts |
| Continuous rated power (20-20k Hz, THD | 2100 Watts |
| Continuous rated power (20-20k Hz, THD | 1050 Watts |
| Maximum bridged output 4Ω | 7000 Watts |
| Maximum bridged output 8Ω | 5000 Watts |
| Input Sensitivity (Rated Power @8 Ohms) | 0 / +6 / +9 dBu (Switchable) |
| THD at Rated Output Power | |
| IMD-SMPTE (60Hz, 7kHz) | |
| Max. Input Level | +22 dBu (9,75Vrms) |
| Crosstalk (1kHz, Rated Output Power) | < -80dB |
| Frequency Response (ref. 1kHz) | 10 Hz - 30 kHz (± 1dB) |
| Input Impedance | 20 kOhms |
| Damping Factor (1 kHz) | > 400 |
| Slew Rate | 35 V/μs |
| S/N Ratio (A-weighted, 32dB Gain) | 111 dB |
| Output Noise, A-weighted | < -70 dBu |
| Output Stage Topology | Class-H Grounded Bridge |
| Power Requirements | 100 - 240V, 50/60 Hz or 100V, 50/60 Hz |
| Power Consumption1/8 Max. Output @ 4 Ohms | 1450 W |
| Cooling | Front-to-Rear, 5-Stage Fans |
| Ambient Temperature Limits | +5°C - +40°C(40°F - 105°F) |
| Dimensions (H x W x D) | 3.46" (88.1 mm) x 19" (483 mm) x 15" (512 mm) |
| Weight | 32 lbs (14.5 kg) |
