The Furman Merit M-8S Power Sequencer is the perfect low-cost AC power solution for any rack mount system. Install an M-8S in your rack, and the eight outlets in the rear panel will power up in sequence and protect all your equipment up to a 15-amp load.

Features

Features

Standard level AC protection and filtering
Six sequenced rear panel outlets (in 3 groups), two unswitched rear panel outlets, and one front panel unswitched outlet
Momentary and Maintained sequencing via rear panel terminal block or front panel switch (momentary only)
All settings and configurations available on rear panel
15 amp rating
Three year limited warranty

Specification

Maximum Output Current	15 amps, 120 VAC (Thermal breaker)
Line Cord	14AWGx3, 10 ft, black, fixed, NEMA 5-15P plug
AC Receptacles	Convenience Outlet (Front Panel) 1 Un-switched NEMA 15-5R Rear Panel Outlets: 2 Un-switched NEMA 5-15R (1 duplex) 6 Sequenced NEMA 5-15R (3 duplexes, each controlled by separate relay)
Standard Level AC Surge Protection	Merit Class (sacrificial)
Spike Protection Mode	Line to neutral, zero ground leakage
Max Continuous Operating Voltage	130V RMS
Max Clamp Voltage	500 Volts Peak
Peak Impulse Current	12,000 Amps
Energy Rating (2 X 820Î1/4S)	225 Joules
AC Filtering	Standard level Pi LCR Filter
Noise Attenuation	>26dB, 100 Khz to 1 MHz
Operating Temperature Range	5C (40F) to 40C (105F) degrees
Humidity Range	<90% rH (Relative Humidity)
Rocker Switch	Front panel, Sequence (ON, OFF)
Thermal Circuit Breaker	Front panel, push to reset
Front Panel Indicators	Delay 1, Delay 2, Delay 3, Power, Protection OK
Rear Panel DIP Switches	12V Mode On/Off, GND Mode On, Momentary/Maintained
Potentiometer	Rear panel, time calibration fine tune delay adjust
Remote Terminal	+5-30VDC In, 12VDC (12mA) Out Phoenix type 4-Pin Connector with Screw terminals +12V, STAT, REM, GND (Class 2 Wiring)
Power Consumption	5W
Safety Agency	C/CSA/US
Dimensions (H x W x D)	1.75" (44.5 mm) x 19" (483 mm) x 8.75" (222.3 mm)
Weight	7 lbs (3.18 kg)
