| Components |
Six (6) 165 mm (6.5 in) LF Drivers Twenty-Four (24) 25 mm (1 in) HF Drivers |
| Frequency Range (-10 DB) |
45 Hz - 20 kHz |
| Sensitivity (2.83V@ 1m) |
102 dB (at Highest Sensitivity Setting: “Point” Pattern Up, “Point” Pattern Down, “Speech” Voicing, in Free Space); 95 dB (at Lowest Sensitivity Setting: “Medium” Pattern Up,“Downfill” Pattern Down, “Music” Voicing in Free Space) |
| Nominal Impedance |
4 ohms (4 ohms above 1 kHz; 8 ohms Below 800 Hz) |
| Power Capacity |
1500W (6000W Peak), 2 hrs; 1000W (4000W Peak), 100 hrs |
| Maximum Input Voltage |
65.0 Volts RMS (2 hrs), 130.0 Volts Peak |
| Max SPL |
Highest Directivity Setting: (“Point” Pattern Up, “Point” Pattern Down) with “Speech” Voicing: 131 dB Continuous Average Pink Noise, 134 dB Continuous Program, 137 dB Peak |
| Max SPL |
Highest Directivity Setting: (“Point” Pattern Up, “Point” Pattern Down) with “Speech” Voicing: 127 dB Continuous Average Pink Noise, 130 dB Continuous Program, 133 dB Peak |
| Max SPL |
Lowest Directivity Setting: (“Medium” Pattern Up, “Downfill” Pattern Down) with “Speech” Voicing: 128 dB Continuous Average Pink Noise, 131 dB Continuous Program, 134 dB Peak |
| Max SPL |
Lowest directivity Setting: (“Medium” Pattern Up, “Downfill” Pattern Down) with “Music” Voicing: 124 dB Continuous Average Pink Noise, 127 dB Continuous Program, 130 dB Peak |
| Recommended High-Pass |
35Hz, 24 dB/oct or greater |
| Low Frequency Drivers |
6 pcs, 165 mm (6.5 in) drivers, lightweight neodymium motors, 50 mm (2.0 in) diameter voice coils, copper-capped pole tips to minimize flux modulation and linearize inductance, 16 mm (0.63 in) long coil for high linear drive and high power handling, damped blended textile surround, coated cones for moisture, UV and salt resistance. Magnetically shielded |
| High Frequency Drivers |
24 pcs, 25 mm (1 in) drivers, neodymium, encased magnet and coated diaphragm for moisture, UV, and salt resistance |
| Enclosure |
Fiberglass Reinforced ABS Cabinet, Powder Coated 1050 Aluminum Grille |
| Outdoor Capability |
IP-55 rated, per IEC529, when installed with optional MTC-PC2 cover. ASTM G85 for acid-air/salt-spray (200 hrs) |
| Colors |
Black (RAL9004) or White (-WH) (RAL9016) |
| Insert Points |
14 individual M8 inserts on back panel (20 mm deep) for use with swivel (pan)/tilt bracket(s), forged-shoulder steel eyebolts, swivel rings, and after-market third-party brackets, plus 4 individual M8 inserts on top and 4 on bottom of cabinet end-caps |
| Mounting |
Included two-part swivel (pan)/tilt wall bracket provides continuously variable +/- 45° left-right swivel aiming (at no up/down tilt), +/- 15° tilt in 1° fixed increment points. Fourteen threaded mounting points located on back panel of cabinet conform to industry standard rectangular 5" x 2.75" pattern for legacy OmniMount® and other compatible third-party brackets. Four threaded mount points on the top end-cap and four on the bottom end-cap. Threaded mounting points can be utilized for suspension |
| Included Accessories |
Two-Piece Swivel (Pan)/Tilt Wall Bracket |
| Optional Accessories |
MTC-PC2 terminal panel cover MTC-CBT1K-ACC1 Accessory kit includes: 2 pcs MTC-CBT-FM3 flush-mount brackets 1 pc MTC-CBT-OS3 offset bracket (for CBT 1000+1000E array – works in conjunction with CBT 1000E’s included Coupler Plate for locating CBT 1000E extension cabinet above CBT 1000 instead of below it) MTC-CBT-SUS3 CBT Series suspension bracket kit (2 pcs included to provide top and bottom attachment points) |
| Dimensions (H x W x D) |
40.2" (1020 mm) x 9.9" (250 mm) x 13.6" (345 mm) |
| Net Weight |
54 lbs (24.5 kg) |
| Shipping Weight |
85 lbs (38.6 kg) |
