The JBL Control 65 P/T incorporates JBL’s exclusive RBI Radiation Boundary Integration technology to provide very consistent, wide coverage throughout the listening space.

Description

JBL Control 65 P/T Compact Full-Range Pendant Speakers

The Control 65P/T is a compact full-range, two-way pendant-type loudspeaker that provides superb sound reproduction and very consistent, wide coverage for rooms with open architecture ceilings and other locations where a pendant form factor is desired. JBL’s patent-pending Radiation Boundary Integrator® (RBI) technology, adapted from the groundbreaking VERTEC™ Series of line array loudspeakers, delivers consistent coverage of the listening area. Combining a large 8" (200 mm) diameter waveguide with low-frequency projection apertures, the two coaxially-mounted drivers provide a seamless integration of coverage, resulting in extremely even pattern control and coverage where all listeners hear a consistent, high-fidelity sound quality. The wide 120° coverage pattern allows for the use of fewer speakers, reducing the cost of the installed system without sacrificing performance.

Excellent sound quality coupled with stylish design and easy installation makes the Control 65P/T ideal for a wide variety of applications including retail, restaurants, hotels, casinos, fitness centers, convention centers, exhibit spaces, conference rooms, atriums, museums, transit centers and other open-ceiling applications. The Control 65P/T includes a single-point mounting system for easy and secure suspension in open-ceiling applications. Two complete hanging cable systems are included, providing both main and safety suspension cables. Include are extra-long 4.5 m (15 ft) high tensile galvanized steel wire rope having spring clips for the loudspeaker end of the cable and UL listed cable fasteners for infinitely adjustable suspension height. The system’s 5.25" (130 mm) low-frequency driver features a polypropylene-coated cone and 1" (25 mm) copper voice coil with vented fiberglass resin coil-former for high power handling and improved long-term reliability.

Features

  • Ultra-compact
  • A large-diameter, high-frequency waveguide with low-frequency projection provides a seamless integration of coverage
  • RBI technology to provide very consistent, wide coverage throughout the listening space
  • 120-degree conical coverage
  • comes with a 60W multi-tap transformer
  • Available in black or white

Specifications

Frequency Response (-10 dB) 55 Hz – 20 kHz
Frequency Range (±3 dB) 78 Hz – 18 kHz
Power Capacity 75W Continuous Pink Noise Power (with 300W peaks)
150W Continuous Program Power
Nominal Sensitivity 86 dB
Nominal Coverage Angle 120° (+20°/-10°)
Directivity (Q) 5.3
Directivity Index (DI) 7.2 dB
Rated Maximum SPL @ 1m 105 dB continuous pink noise, 111 dB peak
Rated Impedance 8 ohms
Transformer Taps 70V: 60W, 30W, 15W & 7.5W
100V: 60W, 30W, 15W
Transformer Insertion Loss 0.5 dB @ 7.5W, 0.5 dB @ 15W, 0.6 dB @ 30W, 0.7 dB @ 60W
LF Driver 5.25" (30 mm) polypropylene-coated paper with pure butyl rubber surround
1" (25 mm) copper voice coil, vented fiberglass resin voice coil-former
HF Driver 0.75" (20 mm) textile soft-dome, neodymium magnet assembly, ferro-fluid cooling, aluminum voice coil former
Enclosure Material High impact polystyrene
Grille Zinc-plated steel grille with powder-coat finish, foam backing (removable for painting)
Environmental Exceeds Mil Spec 810 for humidity, salt spray, temperature & UV. IP44 capability per IEC 529 – splashproof rating
Termination Two removable locking euro-block 2-pin connectors with screwdown terminals for bare wire. Connectors paralleled for input and loop-thru. Max. wire 12 AWG (2.5 mm). Rubber terminal covers included
Included Accessories Two suspension cable systems, two 2-pin removable locking euro-block connectors, two rubber covers for euro-block connectors
Optional Accessories MTC-PC60 top panel / terminal cover
Dimensions (Dia x H) 9.3" (234 mm) x 10.2" (259 mm)
Net Weight (ea) 8 lbs (3.7 kg)
Shipping Weight (Pair) 19 lbs (8.7 kg)
