Three of the revolutionary new D2 Dual-Diaphragm Dual-Voice-Coil Compression Drivers mounted on a 3rd generation waveguide and patented RBI – Radiation Boundary Integrator assembly. Patented rigging, Crown VRack DSP and amplification, and JBL HiQnet Performance Manager configuration and control software complete the system package.
The revolutionary D2 Dual Driver dramatically improves the sound and performance of high frequencies, providing an extreme output advantage over conventional systems with significantly higher array power, reduced distortion, double the number of voice coils and more than double the power handling. This results in a dramatic increase in pure high frequency sound pressure levels in the same physical footprint with a 30% reduction in weight.
JBL's patented Radiation Boundary Integrator combines the high frequency and mid-range sections of the VTX V25 so the transition across each band is uninterrupted, undistorted and seamless. A patented, tuned resonant-chamber is integrated into the waveguide itself, effectively eliminating throat-related cancellations due to back pressure from the mid-range section. VTX's refined RBI waveguide implementation provides improved horizontal coverage - broader and more stable.
