Juice Goose RX 50 AC Line Surge Protector

A Cleaner Ground from a Slim Line Enclosure

The RX 50 features the non-sacrificial Juice Goose Hybrid Filter Technology to improve performance of electronic components and protect against dangerous power line surges on the hot, neutral and ground power leads.

Additional features include:

•     15 Amp Capacity
•     High Voltage Surge Protection
•     High Frequency Normal and Common Mode Noise Filtration
•     Over Voltage Shutdown
•     Protection Against Building Wiring Faults
•     Three power receptacles



Juice Goose RX Series technology reduces ground line (common mode) surges to a maximum of 0.50 (on half) volt. While ground line surges and disturbances don't typically cause catastrophic damage, they can result in operating failures and improper performance of digital processing equipment.

The non-sacrificial Hybrid Filter Technology also protects against more dramatic events. Connected equipment is safe from surges up to 6,000 volts at 3,000 amps on between hot and neutral. The RX Series circuitry allows a maximum 10.0 volt normal mode surge.

The RX Series will not contaminate the ground. Instead, it cleans it up.

RX 50 Features

Slim line RX 50 measures only 1.75" x 9" x 9.5". It has three NEMA 5-15R receptacles to connect and protect multiple components in a small space.  LEDs on the front indicate power connection, external wiring faults and protection OK status.
