K-Array KF12MT 12" Powered Loudspeaker (Discontinued)

K-Array KF12MT 12" Powered Loudspeaker (Discontinued)

Name: K-Array KF12MT 12" Powered Loudspeaker (Discontinued)
Brand: K-Array
SKU: KARRAY-KF12MT
Price: 4703.48 USD
Availability: OutOfStock

Write a Review

Part #:

KF12MT

Model #:

KF12MT

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The KF12MT replaces the KF12, effective immediately. The updated model offers a host of new features including on-board touchscreen control of DSP settings, delay functionality (up to 400 ms), as well as both analog and digital inputs.

Description

The K-Array KF12MT Powered Loudspeaker is ideal for stage monitoring, or for use as a main PA system for small to medium sized events. For stereo applications, the KF12MT can be easily extended with the KF12P, passive variant.

Features

Symmetrical horizontal and vertical coverage
Integrated DSP with analog and digital inputs
On-board touch screen with matrix control
Configurable full range powered output
RS485 and USB connectivity for remote control
Angled cabinet for floor monitor use
Integrated 35mm pole adapter

Specifications

Acoustics
Speaker power handling	800 + 200 W (AES)
Frequency range (-10 dB)	55 – 19 kHz
SPL 1W/1mt	99 dB
Maximum SPL	127 dB (cont.) – 133 dB (peak)
Coverage
Horizontal	70°
Vertical	70°
Crossover
TypeFrequency	Internal Passive Crossover
Transducers
Coaxial Transducer	12” Neodymiun magnet Woofer with 3” voice coil
Audio Input
Analog connectors	2 male + 2 female 3-pin balanced XLR
Digital connectors	1 male + 1 female 3-pin XLR
Remote Control Input
Connector	1 male + 1 female XLR parallel / 1 USB B Jack serial converter
Audio Power Output
Connector	1 x Female 4-pin Speakon
Wiring	Pin1+= CH1+ Pin1- = CH1- Pin2+= N.C. Pin2= N.C.
Power Input
Connector	2 x PowerCon IN/OUT
Amplifier
Type	1 module class D – DSP controlled
Nominal power output	2 X 1050 W @ 8 Ω 1% THD + NOISE
Protection	Dynamic Limiter , Over Current , Over Temp. Short Circuit
Frequency response	10 Hz – 25 KHz (+/- 3 dB) for 1W @ 8 Ω
Damping factor 8Ω, 100 Hz	> 500
THD+N 1KHz, 1 W	0.010%
Thermal dissipation	1/8 of max output power @ 8Ω = 282 BTU/h (71KCal/h)
Thermal dissipation	1/4 of max output power @ 8Ω = 464 BTU/h (117KCal/h)
AC Power
Nominal voltage	115 / 230 Vac auto switching
Operating range	85 - 130 Vac 60Hz / 190 - 240 Vac 50Hz (Auto Switch)
I. Nom	5.5 A / 115 Vac - 2.9 A / 230 Vac
Efficiency	>80% (typical)
1/8 rated power (pink noise) @ 4 Ω	410 W
Dimensions	15.37" (390.40 mm) x 20.55" (521.97 mm) x 14.38" (365.25 mm)
Weight	41.45 lbs (18.8 kg)
